VT5804 Pro 5.8G 48CH 25mW/200mW/600mW Switchable S.BUS FPV Transmitter

Attention: Now this item was upgraded in 48CH. We would update the photos as soon as possible.
06/05

Specification: ( Manual)
Item Name: 5.8G 48CH 25/200/600mW Switchable FPV Transmitter
Model: VT5804 Pro
Input Voltage: 7-24V
Power: 25/200/600mW (Switchable)
Transmission Distance: 0.5KM+@25mW; 1KM@200mW; 2KM+@600mW
Connector: MMCX
Antenna: IPEX
Video Format: NTSC/PAL
Frequency: 48CH , 16CH in E for Raceband
Output Impedence: 50Ohm
Output Power: 28dbm
Video Band Width: 0-8.0Mhz
Audio carrier requency: 6.5Mhz
Video Input Level: 08-1.2Vp-p
Weight: 6g (without antenna)
Size: 36x36x5mm (LxWxH)

Frequency Table and Setting:
S.Bus Long-range Control:
Input S.Bus sign to VTX, change the CH1-CH8 in the original FR (A-E) by the Radio Remote Controller's 6th Channel.

Button Power Control:
1. Long press the button 10 Seconds, then short press would change the power 25/200/600.
2. Short Press one time, will change the Channel ( CH1-CH8)
3. Long press 2 Senconds and then short press , will change the FR ( A-E)


Package Included:
1x VT5804 Pro Transmitter
1x IPEX Antenna
