Specification:
XXD Brushless Motor:
Mode: A2212
KV:1000 KV
Max Efficiency: 80%
Max Efficiency Current: 4-10A (>75%)
Current Capacity: 12A/60s
No Load Current @ 10V: 0.5A
No. Of Cells: 2-3 Li-Poly
Motor Dimensions: φ27.5 x 27mm
Shaft Diameter: φ3.17mm
Weight: 48g
Suitable for RC FPV Racing Drone
30A Brushless ESC:
Output: Continuous 30A, burst 40A up to 10 Secs.
Input voltage: 2-4 cells lithium battery or 5-12 cells NiCd/NIMh battery
BEC: 2A / 5V (Linear mode).
Max speed: 210,000rpm for 2 poles BLM, 70,000rpm for 6 poles BLM, 35,000rpm for 12 poles BLM.(BLM: Brushless Motor)
Size: 45 * 24 * 11mm / 1.8 * 0.9 * 0.4in
Weight: 25g / 0.9oz
Multi Servo Tester:
Voltage consumption: DC4.8-6V
Size: 48 x 42 x 17mm
Color: Blue
Net weight: 7g
Power Supply:
Input:100V-240V 50/60Hz 1.6A
Output: 12V 5A
Features:
1.Safety Arming Feature: Regardless the throttle stick position, the motor will not spin after battery connected.
2.Throttle Calibration: Throttle range can be configured to provide best throttle linearity, fully compatible with all market available transmitters.
3.Programmable Items:
Brake Setting: brake enabled / brake disabled.
Battery Type: Li-xx(Li-ion or LiPo) / Ni-xx(NiMh or NiCd).
Low Voltage Protection Mode(Cutoff Mode): Gradually reduce the output power / Cutoff the output power.
Low Voltage Cutoff Protection Threshold (Cutoff Threshold): low / medium / high.
Start Mode: normal / soft / very soft.
Timing: low / medium / high.
Reset: reset all the programmable items to their default settings.
4.Full Protection Features: Low voltage cutoff protection / Over-heat protection / Throttle signal lost protection.
Features of Servo Tester:
CCPM Servo Consistency Master / Servo tester
The device also can be used as a signal generator for electric speed controller (ESC), then you can test your motor system without using a transmitter and receiver.
There are 3 modes to check servos or ESC:
Manual mode: turn the knob with different speed, check the reaction time.
Neutral mode: make the servo go back to the neutral point.
Automatic "window wiper" mode: make the servo swing like a window wipers in the biggest angle.
It can connect 1-3 servos simultaneously and test such as 1-3 servos consistency and so on.
You can also connect 1-3 ESC to test and compare their reaction time respectively.
It can connect 3 servos of the CCPM helicopters and select servos.
It can also connect the servo of airplanes install the steering-box and adjust planes by using such as the neutral mode and so on.
Packaging included:
Packaging included:
1X XXD A2212 1000 KV Brushless Motor
1X 30A ESC
1X Servo Tester
1X Power Supply
1X 1047 Propeller
1X 30A ESC
1X Servo Tester
1X Power Supply
1X 1047 Propeller
