XPKRC X3 135mm F4 20A BL_S FPV Racing Drone w/ 40CH VTX Runcam Micro Sparrow 2 Camera PNP - 139.00 €

XPKRC X3 135mm F4 20A BL_S FPV Racing Drone w/ 40CH VTX Runcam Micro Sparrow 2 Camera PNP
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


XPKRC X3 135mm F4 20A BL_S FPV Racing Drone w/ 40CH VTX Runcam Micro Sparrow 2 Camera PNP

Specification:
Brand Name: XPKRC
Model: X3
Item Name: 135mm Omnibus F4 FPV Racing Drone
Version: PNP ( Without Receiver)
Drone Wheelbase: 135mm
Bottom (Arm) Plate Thickess: 3mm
Side Plate Thickness: 2mm
Empty Frame Weight: 22.6g
Drone Weight: 86g ( Not include battery)

F4 Flight Controller Item Name: Omnibus F4 FC AIO OSD BEC
Firmware: OmnibusF4
Input Voltage: 2-4S Lipo
- w/ Betaflight OSD
- [email protected] BEC
- MPU6000 6 Aixs SPI Gryro & Accelerometer
Size: 27x27mm
Mounting Hole: 20x20mm
Weight: 3.5g
- Support DShot1200
- Support SBUS / PPM / DSMX DSM2 Receiver
20A BL_S 4 in 1 ESC Item Name: 20A BLheli_S 4 in 1 ESC
Input Voltage: 2-4S Lipo
Con. Current: 20A
Peak Current: 25A
BEC: NO
Size: 29x31mm
Mounting Hole: 20x20mm
Weight: 4.9g
- Support DShot150/ DShot300 and DShot600
( Don't recommend PWM)
Brushless Motor Item Name: 1106 4500KV Motor
Brand Name: SPC Maker
3024 3-Blade Propeller Item Name: Emax AVAN Mini 3 Inch Propeller
Brand Name: Emax
Model: AVAN Mini 3 Inch
Color: Transparent Black
FPV Transmitter Item Name: 5.8G 40CH 25mW / 100mW VTX
Input Voltage: 5-6V
Operation Current (5.5V): 310mA@25mW ; 350mA@100mW
FPV Camera Item Name: Runcam Micro Sparrow 2 700TVL Camera
Brand Name: Runcam
Model: Micro Sparrow 2
Image Sensor: Super WDR CMOS Sensor
Horizontal Resolution: 700TVL
Lens: 2.1mm ​(M8)​ FOV150°
Screen Format: 4:3
Signal System: NTSC
Mirror/Flip: Available
Integrated OSD: Yes
One Touch Scene Setting: Personal / Lightrax / Outdoor / Indoor / Cloudy / Twilight
S/N Ratio: >50dB
Electronic Shutter Speed: Auto
Min. Illumination: [email protected]
WDR: Super WDR
Day/NightAuto
Power: DC 5-36V
Current: 120mA@5V / 50mA@12V
Net Weight: 4.5g
Dimensions: L19mm*W19mm*H17mm


































































Package Included:
1x XPKRC X3 135mm FPV Racer PNP Version
