XL24L01-D03 2.4G NRF24L01+ 1000m RF Wireless Module With Antenna

XL24L01-D03 modules using imported Norwegian NORDIC latest generation high-speed 2.4G wireless transceiver chip NRF24L01 + well-designed, half-duplex modules, each module can receive and send at least two modules can be achieved using point to point wireless data communication


XL24L01-D03 module can be widely used in a variety of short-range wireless data communications, such as: wireless data collection, toys, smart home, remote controls, wireless voice, wireless headphones, wireless sensors, intelligent terminal, etc.

Descirpion:
Item Name: RF Wireless Module
Item No.: XL24L01-D03
Frequency: 2.4G global open license-free ISM band using
Maximum operating rate: 2Mbps
Modulation,GFSK anti-interference ability
CH: 125 channels
Operating voltage: 3.0-3.6V,
Transmit power: 18dBm
Emission current 90mA
Receive Current: 22mA
Sleep current: 1.1uA
External 2.4GHz antenna
Dimension: 18mm * 30mm

Features:
XL24L01-D03 is manufactured NORDIC based on the original design professional, the most fitting of various properties NRF24L01.
Murata high frequency module device used in all specifications inductance and capacitance, crystals of 10ppm precision specifications ensure that the wireless feature modules are fully reflected.
Using environmentally friendly lead-free solder SMT precision machining, all modules have been professional equipment testing, uniformity and stability modules are fully protected.
Pin is fully compatible with other specifications on the market 8Pin double 24L01 interface modules can be directly replaced upgrade
SPI interface, the module can be software set address, frequency, modulation rate and other parameters, only the local address will receive the output data (provided interrupt instruction), can be directly connected to a variety of microcontroller, software programming is very convenient
2.54mm pitch DIP standard interfaces for embedded applications.
Open field test distance of about 1000 m @ 250KBPS, this distance is only for reference, the different operating modes, the amount of data and test environments for distance varying degrees of influence.

Package included:
1PC XL24L01-D03 2.4G NRF24L01+ 1000m RF Wireless Module NRF24L01+PA+LNA+Antenna
