| Specification | |
| Brand name | X-MAN |
| Item name | 223mm FPV Racing Drone |
| Frame Kit |
Wheelbase: 223mm Arm board: 4mm Upper board: 2mm |
| Flight Controller |
OMNIBUS F3 CPU: STM32F303CCT6 Sensor: MPU6000 triaxial accelerometer/triaxial gyroscope (SPI connection) Power supply: 2-6S battery input BEC: Built-in 5V/3A Receiver: Support Sbus or serial RX interface, Spektrum 1024/2048, SBUS, IBUS, etc. Supports 3.3v Spektrum Satellite Receiver Support PPM receiver Integrated buzzer alarm Reserved IIC interface Support programmable LED_Strip (turn off Transponder before use) Support BLheli suite ESC programming Built-in voltage detection and alarm Built-in OSD function, BF online reference |
| ESC |
4 IN 1 35A Blheli_S ESC DSHOT600 Voltage: 2-6S Continuous current: 35A (Hardware drive has been upgraded) Weight: 12.2 grams Support 150Dshot 300 Dshot 600 Dshot, follow-up can be upgraded directly. The Dshot series electrically calls the BB21 MCU.48Mhz Runs BLHELI_S J_H_xx firmware Supports 2-6S, 4PWM input, without BEC Supports Oneshot / Multishot / Dshot BLHELI-S firmware Size 36mm*36mm (standard 30.5mm mounting hole distance) |
| VTX | 48CH 25mw/100mw/200mw/400mw/600mw switchable OSD |
| Motor | DYS R2205 2550KV |
| Propeller | Gemfan 5152 3-blade (color will be sent in random) |
| Camera | 960H camera 200w 1500TVL support OSD, 2.3mm lens , 135 degree |
| Voltage |
3S-6S(11.1V-25.2V) |
| Receiver |
FrSky XM+ receiver , distance get 1000m Flysky AFHDS 2A receiver, distance get 500m |
| Weight/Size |
Drone size: 218*170*45mm Drone weight: 278g (without battery) Package size: 255*205*70mm Package weight: 392g |
Package Included:
PNP Version
1 x 223MM Frame Kit
1 x Omnibus F3 flight controller
1 x 35A ESC
4 x 2205 2550KV Motor
1 x 5.8G 48CH VTX
1 x Camera
4 x CW 5152 propeller
4 x CCW 5152 propeller
BNF Version
1 x 223MM Frame Kit
1 x Flysky receiver/ FrSky receiver
1 x Omnibus F3 flight controller
1 x 35A ESC
4 x 2205 2550KV Motor
1 x 5.8G 48CH VTX
1 x Camera
4 x CW 5152 propeller
4 x CCW 5152 propeller
