Specification:
Frequency: 5.8Ghz
Frequency band: 5362~5945MHz
Channel customer: 48
Modulation type: FM
Channel SEL.: Touch switch
Channel indicate: CH1~CH8 indication with 8LEDS and A~F frequency group indicate with 6LEDS
Transmit power: 13±1dBm
Frequency control: PLL
All harmonic: MAX -50dBm
Frequency stability: ±100KHz(Typ.)
Frequency precision: ±200KHz(Typ.)
Channel carrier error: 1dB
Antenna port: 50Ω
Input format: NTSC/PAL
Frequency band: 5362~5945MHz
Channel customer: 48
Modulation type: FM
Channel SEL.: Touch switch
Channel indicate: CH1~CH8 indication with 8LEDS and A~F frequency group indicate with 6LEDS
Transmit power: 13±1dBm
Frequency control: PLL
All harmonic: MAX -50dBm
Frequency stability: ±100KHz(Typ.)
Frequency precision: ±200KHz(Typ.)
Channel carrier error: 1dB
Antenna port: 50Ω
Input format: NTSC/PAL
Power: 25mW
Input voltage: 2.9-5.5V
Weight: 1g
Can be used for Runcam Micro Swift /Micro Swift 2/Foxeer Micro Arrow V2/RunCam Foxeer Mini Camera
Note: not include the camera
Features:
1. 48 channel
2. Support touch switch select channel frequency group
3. Support NTSC/PAL switch,support vertical inverted image switch
4. 8LED display channel and 6LEDS display frequency group information;1LED dispaly NTSC/PAL and FLIP information
5. Wide lens angle
6. Omnidirectional clover ANT.
7. Miniature and light weight design
Package included:
1 x Transmitter
Can be used for Runcam Micro Swift /Micro Swift 2/Foxeer Micro Arrow V2/RunCam Foxeer Mini Camera
Note: not include the camera
Features:
1. 48 channel
2. Support touch switch select channel frequency group
3. Support NTSC/PAL switch,support vertical inverted image switch
4. 8LED display channel and 6LEDS display frequency group information;1LED dispaly NTSC/PAL and FLIP information
5. Wide lens angle
6. Omnidirectional clover ANT.
7. Miniature and light weight design
Package included:
1 x Transmitter
