| Specification | ||
| Brand name | URUAV | |
| Item name | UR85 | UR85HD |
| Wheelbase | 85mm | 85mm |
| Motor |
Mode: 0805 KV12000 Configu-ration:9N12P Stator Diamter:8mm Stator Length:5mm Shaft Diameter:Φ1.5mm Motor Dimension(Dia.*Len):Φ10.5mm*17mm Weight(g):3.0g No.of Cells(Lipo):1S-3S |
Mode: 1102 KV10000 Configu-ration:9N12P Stator Diamter:11mm Stator Length:2mm Shaft Diameter:Φ1.5mm Motor Dimension(Dia.*Len):Φ13.5mm*16mm Weight(g):2.8g No.of Cells(Lipo):1S-3S |
| Camera |
Caddx EOS2 1/3" CMOS Sensor 1200 TVL 2.1mm lens 16:9 Image size NTSC Global WDR Internal Synchronization |
CADDX Turtle V2 Image sensor: 1/2.7" CMOS sensor Horizontal: 800TVL TV system: NTSC/PAL changeable Video Resolution: 1080P@60fps / 1080P@30fps / 720@60fps Power Input: DC 4.5-20V FPV FOV: 155° Recording FOV: 170° Mini Illumination: 0.01lux Image Resolution: 2 Megapixels Lens: 1.8mm Turbo Eye Lens Working Current: 380mA@5V/160mA@12V (low consumption) OSD Menu: Yes (Support Voltage Display) Video Files: MP4 Audio: Support Electronic Shutter : PAL : 1/50-100,000 NTSC : 1/60-100,100 S/N Ratio: >60dB (AGC OFF) Video Output: CVBS Max Micro SD Card Supported: 8-64GB(need Class 10 or above, recommend Class 10/UHS-I/UHS-II) Color: Red |
| Flight controller |
(Frsky version) CRAZYBEE F4FR PRO V2.0 Firmware target: CrazybeeF4FR (Flysky version) CRAZYBEE F4FS PRO V2.0 Firmware target: CrazybeeF4FS (DSM2/DSMX version) CRAZYBEE F4DX PRO V2.0 Firmware target: CrazybeeF4DX (No RX version) CRAZYBEE F4 PRO V2.0 Firmware target: CrazybeeF4DX MCU:STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000(SPI connection) Board size: 28.5 * 28.5MM Power supply: 1-3S battery input (DC 3.5-13V) Built-in 5A(each) Blheli_S 4in1 ESC Dshot600 ready Frsky version Built-in SPI Frsky receiver with telemetry(D8/D16 switchable) Flysky version Built-in SPI Flysky receiver with telemetry(AFHDS/AFHDS2A switchable) DSM2/X Version built-in Serial-based DSM2/DSMX compatible satellite receiver No RX version need to add external Receiver Built-in Betaflight OSD(SPI Control) Built-in Current meter Max 28A Current meter scale set to 1175 Built-in 5V 1A Buck / Boost with LC filter Built-in voltage detection |
|
| Onboard 4in1 ESC |
MCU upgraded to EFM8BB21 Power supply: 1-3S LiPo/LiPo HV (3.5v/13v) Current: 5A continuous peak 6A (5 seconds) Support BLHeliSuite programmable Factory firmware: S_H_50_REV16_7.Hex Default protocol: DSHOT600 |
|
| Frsky NON-EU receiver Version |
SPI BUS receiver Frsky D8/D16 switchable Compatible Non EU transmitter both D8 and D16 mode Channels: 8ch or 16ch Failsafe support No ground interference ( Transmitter and receiver 1 m from the ground): 300m |
|
| Flysky receiver Version |
SPI BUS receiver Protocol: AFHDS and AFHDS-2A Switchable Channels: 8ch(AFHDS) or 14ch(AFHDS-2A) No ground interference ( Transmitter and receiver 1 m from the ground): 300m Failsafe support |
|
| DSM2/DSMX receiver version |
Serial bus receiver Protocol: DSM2/DSMX compatible Channels:6-9 (Depend on your radio) No ground interference ( Transmitter and receiver 1 m from the ground): 300m |
|
| PNP No RX version | No RX version support external serial-bus receiver like xm+, crossfire, S-FHSS etc. | |
| VTX |
Output power: 25~200mw switchable Frequency: 40CH Input voltage: 3.3V 5.5V Current consumption: 300mA(type) Antenna: RG178 antenna Frequency: 5.8GHz 5bands 40 channels With Raceband Smartaudio ready Weight: 3g |
|
| Lipo Battery |
Capacity:300mAh Voltage:11.4v Continuous Discharge Rate: 40C Instantaneous discharge rate: 80C Size: 65mmx18mmx11mm Weight: 25g Connector: XT30 |
|
| Size | 112mm*112mm*60mm | 112mm*112mm*60mm |
| Weight | 43g(without battery) | 52g(without battery) |
| Weight | 68g(with Original 3s 300mah Lipo battery) | 76g(with Original 3s 300mah Lipo battery) |
Feature:
UR85 FPV Racing Drone
New Crazybee F4 PRO V2.0 AIO Flight controller 1-3s Lipo Compatible
Betaflight support , multi flight mode: ACRO/AIR/ANGLE
Powerful and smoothly
Betaflight OSD support ,easy to get RSSI, Voltage ,current from your goggles(DSMX version no RSSI output)
Caddx EOS2 camera
Camera Angle adjustable
VTX power switchable 25mw~200mw
Smartaudio ready , change VTX bands, powers, channels via OSD
Frsky Non-EU version support NON-EU Frsky transmitter D8/D16 compatible
Flysky version support both AFHDS and AFHDS-2A protocol transmitter
DSM2/DSMX version support DSM2 and DSMX compatible Spektrum transmitter
No RX version support external serial-bus receiver like xm+, crossfire, S-FHSS etc..
Full telemetry function ready (Frsky Non-EU and Flysky version support)
Real Bind and Fly version
Compatible both for 2s-3s Lipo/LIHV
UR85HD FPV Racing Drone
New Crazybee F4 PRO V2.0 AIO Flight controller 1-3s Lipo Compatible
2S for indoor Cine whoop mode
3S for outdoor Freestyle whoop mode
Betaflight support , multi flight mode: ACRO/AIR/ANGLE
1102 brushless motor only 2.8g with double ball bearings
Powerful and smoothly
Betaflight OSD support ,easy to get RSSI, Voltage ,current from your goggles(DSMX version no RSSI output)
Caddx turtle v2 + 1080p 60fps DVR ready
Camera Angle adjustable
VTX power switchable 25mw~200mw
Smartaudio ready , change VTX bands, powers, channels via OSD
Frsky Non-EU version support NON-EU Frsky transmitter D8/D16 compatible
Flysky version support both AFHDS and AFHDS-2A protocol transmitter
DSM2/DSMX version support DSM2 and DSMX compatible Spektrum transmitter
No RX version support external serial-bus receiver like xm+, crossfire, S-FHSS etc..
Full telemetry function ready (Frsky Non-EU and Flysky version support)
Real Bind and Fly version
Compatible both for 2s-3s Lipo/LIHV
Package Included:
UR85 FPV Racing Drone Version
1 x UR85 85mm Frame
1 x Option1: Crazybee F4FR V2.0 PRO FC built-in Frsky NON-EU RX
Option2: Crazybee F4FS V2.0 PRO FC built-in Flysky RX
Option3: Crazybee F4DX PRO FC built-in Serial-bus DSM2/DSMX RX
Option4: Crazybee F4 V2.0 PRO FC no RX verion
4 x 0805 KV12000 Motor
1 x 1.9inch propeller(4cw+4ccw)
1 x Caddx EOS2
1 x 5.8G 40ch 25mw-200mw VTX
1 x 3S 11.4v 300mah 40C/80C battery
1 x Propeller disassemble tool
1 x Screwdriver
UR85HD FPV Racing Drone Version
1 x UR85HD 85mm Frame
1 x Option1: Crazybee F4FR V2.0 PRO FC built-in Frsky NON-EU RX
Option2: Crazybee F4FS V2.0 PRO FC built-in Flysky RX
Option3: Crazybee F4DX PRO FC built-in Serial-bus DSM2/DSMX RX
Option4: Crazybee F4 V2.0 PRO FC no RX verion
4 x 1102 KV10000 Motor
1 x 1.9inch propeller(4cw+4ccw)
1 x Caddx Turtle v2+1080p 60fps DVR
1 x 5.8G 40ch 25mw-200mw VTX
1 x 3S 11.4v 300mah 40C/80C battery
1 x Propeller disassemble tool
1 x Screwdriver
