Specification:
Brand Name: URUAV
Item Name: VTX Camera
Output power: 25mw
Frequency: 48CH
Input voltage: 3.3V 5.5V
Current consumption: 300mA(type)
Camera resolution: 700TVL
Field of view: 120°
Video Format: NTSC
Antenna: RG178 antenna
Frequency: 5.8GHz 6 bands 48 channels
With Raceband: 5474 5945 MHZ
Size: 13.9"12.0mm ( L*W )
Weight: 3g
Parameters:
Frequency switching: By one button, Short press the button to change channel, 1-8 adjustable.
Press and hold the button for 2s to change bands, 1-6 adjustable
Two groups of LEDs :
Group 1:6 BLUE LED stand for bands.
Group 2:8 RED LED stand for channels.
Blue LED1 and Red LED1 light on, 5865MHZ ( BAND1 and CH1 )
Blue LED1 and Red LED2 light on, indicating frequency 5845MHZ ( BAND1 and CH2 )
Blue LED6 and Red LED8 light on, indicating frequency 5600MHZ ( BAND6 and CH8 )
Package Included:
1 x VTX Camera
