The UP100AC QUAD Charger is a four channels identical and independent 100watt power outputs and built-in power supply, total output is 400 Watts. Each channel is capable of charging all types batteries at up to 10.0 A and discharge at 0.1-5.0A, it include 4sets fan cooling system and an internal sensor for controlling fan speed, internal cell balancers, high contrast LCD displays and important warning and safety function

Feature:

1.Charges 1-6 cell LiPo, LiFe and Li-ION, 1-15 cell NiCd and NiMH and 2-20V lead acid batteries

2.Fast Charge, Balance Charge and Storage Charge modes for lithium batteries

3.Automatically controls current rate during charging and discharging process

4.Four independent 100 watt power outputs charges up to four batteries simultaneously

5.Four independent balancing ports for lithium batteries

6.Five user customizable pre-set per output

7.Four fan cooling system with internal sensor for controlling fan speed

8.Batteries can be set to automatically Charge/Discharge or Discharge/Charge up to a maximum of 10 cycles

9.Automatic charge termination if battery temperature gets too high

10.Temperature probe is required and must be purchased separately

11.PC-based program can analyze the characteristics of each battery via a USB port, graph of voltage, current and capacity curves with individual voltage of each cell in a lithium pack can be displayed on a PC- *PC-LINK USB adaptor is required and must be purchased separately.

Specification:

Input voltage: AC 100-240V

DC 11.0-18.0V

Charge power: 4x100W(400W)

Discharge power: 4x10W(40W)

Charge current range: 0.1-10.0A

Discharge current range : 0.1-5.0A

LiIo/LiPo/LiFe/LiHv cell count: 1-6 series

NiCd/NiMH battery cell count: 1-15cells

Pb battery voltage : 2V-20V (1-10cells)

Current drain for balancing LiPo: 300mah/cell

Battery data memory: up to 10 data

Dimension: 294*199*76mm

Pacakging included:

1X Ultra Power UP100AC QUAD Charger
