TeenyF3 Pro Micro Omnibus F3 Flight Controller 1-2S Built In OSD 16x16mm For RC Drone
Description:
Item name: TeenyF3 Pro flight controller
Size: 20*20mm
Mounting hole: 16*16mm
Diameter: 2mm
Weight: 2.1g
Processor: STM32F303CCT6 (72MHZ, 256K FLASH)
Sensor: MPU-6000 (connected by SPI)
Firmware version: betaflight_3.1.7_OMNIBUS
Voltage regulator module: 5V/0.5A output
Built-in Buck-Boost Converter
Receiver: PPM, Spektrum 1024/2048, SBUS, IBUS, XBUS, SumD SumH RX etc.
Power supply: 1S~2S lipo battery
Suitable for 60mm-80mm mini brushless FPV Quadcopter frame
Features:
Support programmable LED_Strip
Support BLheli/BLHELI_S suite Pass-through ready
Support PPM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600
Support the newest DSHOT ESC
Built-in voltage detection, alarm
Built-in Betaflight-OSD
Buzzer solder pin
LED_STRIP connector
BB ring
Notes:
DSM/DSM2/DSMX, SBUS, Ibus receiver input, please configure RX3(UART3) as input interface.
DSM receiver power from 3.3V.
SBUS and PPM receiver power from 5V.
Package included:
1 x TeenyF3 Pro flight controller
1 x cables
4 x M2*5+5 Nylon column
4 x M2 Nuts
4 x M2 Screw
