Description:
The Tiger Motor F40 PRO II Motor has been designed and built specifically for FPV Racing. This 2150KV version of the F40 PRO II
is designed for drone racing with 5s batteries.
Coming in at only 29.5g, including wires, the F40 PRO II is very light for the power it can dish out. Another amazing feature are the
high temperature silver core windings. These windings are able to withstand much higher temperatures than conventional windings.
Additionally, the top of the stator has an anti-slip design that keeps your props stable during high intensity flights.
Specifcation:
Brand name: T-motor
Item name: F40 Pro II brushless motor
KV: 2150
Configuration: 12N14P
Shaft Diameter: 4mm
AWG: 18#
Internal Resistance: 42mΩ
Motor Dimensions (Dia.*Len): Φ27.9×32mm
Weight with wires(g): 29.5g
Weight without wires(g): 27g
ldle current@10v(A): 1.6A
No.of Cells(Lipo): 3-5S
Cable length: 100mm
Package included:
1x F40PRO II 2150KV Motor
1x Prop Locknut
4x Socket Head Screws
