Description:
Brand Name: T-Motor
Series: AT Series
Color: Blue
Size: 2304
KV: 1800
Max Lipo Cell: 2-3S
No-Load Current (A/10V): 0.5A
Max Current(A)/180S: 13A
Max Power(W)/180S: 110W/2S
Motor Resistance(including line): 138mΩ
Recommended ESC: 15-20A
Recommended Propeller: 7035/8040/9050
Outside Diameter: Short shaftï¿ 28*16.5mm
Stator: Resistant to 150â high temperature coating
No. of Stator Arms/Poles: 12N14P
Shaft Diameter: IN: 4mm, OUT: 3mm
Bearing: Imported 684ZZ bearings
Magnet Level: Resistant to150â temperature
Wire Leading Spec.: Enameled wire leads 40mm
Wire Insulation Grade: Resistant to 220â temperature
Coil Insulation Test: 500V withstand voltage test
Centrifugal Cooling Method: ON
Rotor Dynamic Balance Standard: ≤5Mg
Motor Overall Dynamic Balance Standard: ≤10Mg
Dustproof & Waterproof: IP35
Weight (including wire): 19.7g
Package Weight: 43g
Application: Suitable for RC Airplane
Package Included:
1x T-Motor AT Series AT2304 KV1800 2-3S Brushless Motor
