Sunrise Cicada 30A Blheli_S BB2 2-6S Opto Brushless ESC Support Oneshot125 Multishot for FPV Racer

Specification:
Brand Name: Sunrise
Model: Cicada 30A
Input Voltage: 2-6S
Con.Current:30A
Peak Current(10s):35A
BEC:NO
Programming :YES
Weight:15.8g
Size(PCB):35x19mm


Features:
-Run on BLHeli-S firmware that is designed for superior performance in multirotors

-Use hardware generated motor pwm for smooth throttle response and silent operation

-All codes use damped light mode

-Damped light does regenerative braking, causing very fast motor retardation, and inherently also does active freewheeling

-Support features to prevent sync loss, with tuneable parameters that can make the code run well even in the most demanding situations

-Support regular 1-2ms pulse width input, as well as Oneshot125 (125-250us), Oneshot42 (41.7-83.3us) and Multishot (5-25us)

-The input signal is automatically detected by the ESC upon power up

-Also support a beacon function for finding lost aircraft, the ESC will start beeping after a given time of zero throttle.


Package Included:
1x Sunrise 30A ESC
1x Manual
