Sunnysky New X2206 KV1500 Brushless Motor For RC Models
Description:
Brand Name: SunnysKy
Item Name: X2206 KV1500 Brushless Motor
Prop(inch)
Volts(V)
Amps(A)
Thrust(gf)
Watts(W)
Efficiency(g/W)
Load temperature in 100% throttle
GWS8043
7.4
1.3
100
9.62
10.3950104
61°
2.1
150
15.54
9.652509653
3.2
200
23.68
8.445945946
4.3
250
31.82
7.856693903
5.4
300
39.96
7.507507508
6.8
350
50.32
6.955484897
7.9
390
58.46
6.67122819
11.1
0.9
100
9.99
10.01001001
1.6
150
17.76
8.445945946
2.4
200
26.64
7.507507508
3.2
250
35.52
7.038288288
4.2
300
46.62
6.435006435
5
350
55.5
6.306306306
6.2
400
68.82
5.812263877
7.3
450
81.03
5.553498704
8.5
500
94.35
5.299417064
9.9
550
109.89
5.005005005
11.4
600
126.54
4.741583689
12.9
655
143.19
4.574341784
GWS9047
7.4
1.3
100
9.62
10.3950104
52°
2.1
150
15.54
9.652509653
3.1
200
22.94
8.718395815
4.3
250
31.82
7.856693903
5.7
300
42.18
7.112375533
6.8
350
50.32
6.955484897
8.2
400
60.68
6.591957811
11
490
81.4
6.01965602
GWS1047
7.4
1.2
100
8.88
11.26126126
56°
2
150
14.8
10.13513514
3.1
200
22.94
8.718395815
4.2
250
31.08
8.043758044
5.5
300
40.7
7.371007371
7
350
51.8
6.756756757
8.8
400
65.12
6.142506143
10.7
450
79.18
5.683253347
13.7
525
101.38
5.1785362
GWS9050
7.4
1.2
100
8.88
11.26126126
46°
2.1
150
15.54
9.652509653
3.1
200
22.94
8.718395815
4
250
29.6
8.445945946
5.2
300
38.48
7.796257796
6.6
350
48.84
7.166257166
8
400
59.2
6.756756757
10.1
470
74.74
6.288466685
GWS8040
7.4
1.2
100
8.88
11.26126126
48°
2.1
150
15.54
9.652509653
3.2
200
23.68
8.445945946
4
250
29.6
8.445945946
5.2
300
38.48
7.796257796
6.6
350
48.84
7.166257166
11.1
0.9
100
9.99
10.01001001
1.5
150
16.65
9.009009009
2.3
200
25.53
7.833920877
3.1
250
34.41
7.265329846
3.9
300
43.29
6.93000693
4.9
350
54.39
6.435006435
5.8
400
64.38
6.213109661
6.9
450
76.59
5.875440658
8.1
500
89.91
5.561116672
9.2
550
102.12
5.385820603
11.7
640
129.87
4.928004928
GWS8060
7.4
1.4
100
10.36
9.652509653
52°
2.4
150
17.76
8.445945946
3.6
200
26.64
7.507507508
5
250
37
6.756756757
6.5
300
48.1
6.237006237
8.4
350
62.16
5.630630631
10.3
410
76.22
5.379165573
Note: The test condition of temperature is motor surface temperature in 100% throttle while the motor run 10 min.
Stator Diameter: 22mm
Stator Thickness: 6mm
No. of Stator Arms: 12
No. f Rotor Poles: 14
Motor KV: 1500
No-load Current(A/10V): 0.3A
Motor Resistance: 147mΩ
Max Continuous Current: 13A/30S
Max continuous Power: 150W
Weight: 25.2g
Rotor Diamter: 27mm
Shaft Diameter: 3mm
Body Length: 22.5mm
Overall Shaft Length: 23.3mm
Max Lipo cell: 2-3S
ESC: 12A
Eecommended Prop(inch): GWS8040, GWS8043, GWS9047, GWS9050
AEROBATIC: 300g (3S GWS8040/8043)
180g (2S GWS9047/9050)
240g (3S GWS8040/8043)
Package Included:
1X Sunnysky New X2206 KV1500 Brushless Motor
