Specifications:
Model: 5694
Compatible with: For RC Marine Boats
Material: Silicon Steel, Magnetic Steel, Bearing
Color: Black
Engine Diameter: 56mm
Engine Length: 94mm
Motor Shaft Diameter : 8mm
Motor Shaft Diameter : 8mm
Length of Extend Shaft : 25mm
Compatible Fuel Type: Electric
MPN: 5694 / 800KV
Maximum current: 200A
Maximum voltage: 60v Maximum
Power : 12000w
Idle current: 2.4A
Idle current: 2.4A
Tum: 7D
Maximum speed: 50k
Magnetic pole: 6 Pole
Features:
- With high quality Silicon steel, Magnetic steel and Stock raw materials, make the motor has up to 90% efficiency.
-12000w large output power to provide great power for RC marine boats.
-6 pole brushless motor, 1000R / min rotating speed.
Recommedation:(the packaging do not included)
1.ESC for this motor:300A esc for rc boat
2.SSS 56104 / 420KV 11000W Brushless Motor,please click here
3.SSS 5694/1200KV Brushless Motor,please click here
Note:
The rc boat shown in the picture is not included
Package included:Recommedation:(the packaging do not included)
1.ESC for this motor:300A esc for rc boat
2.SSS 56104 / 420KV 11000W Brushless Motor,please click here
3.SSS 5694/1200KV Brushless Motor,please click here
Note:
The rc boat shown in the picture is not included
1X SSS 5694/800KV Brushless Motor
