Main Features:
- 3K Carbon Fiber Frame
The most sought-after material excels in stiffness and impact resistance. Moreover, the frame consists of modular components, which facilitates maintenance.
- Excellent Brushed FC
The 32-bit open source F3 EVO brushed 2.0 flight controller is a perfect choice for small racing drones. The 32-bit STM32F303CCT6 processor gives you smooth linear motor responses.
- Real-time FPV
Thanks to the 5.8G image transmission system, you are able to watch the 600TVL HD image and enjoy the breathtaking moments.
- Reliable Signal Coverage
Besides RaceBand ( Band D ), 48 channels are available for you to have 5.8G real-time FPV. Therefore, you can get rid of the annoying crosstalk.
- Available Choices
You are allowed to choose DSM2 Satellite / FrSky SBUS PPM / FlySky PPM receiver to work together with your own transmitter.
Specifications:
General
Model: SPC90
Wheelbase: 90mm
Material: 3K carbon fiber
Size: 63.5 x 63.5 x 32mm
Frame weight: 6.5g
Takeoff weight: 55g
Motor: 8520 3.7V coreless motor
Flight time: 5 - 6 minutes
Flight controller: F3 EVO brushed 2.0
Processor: STM32F303CCT6
Camera: 600TVL
FPV transmitter: 5.8G 25mW 48CH
Receiver: DSM2 Satellite / FrSky SBUS PPM / FlySky PPM
Battery: 3.7V 600mAh 25C
Propeller length: 55mm
FPV System
Frequency: 5362 - 5945MHz
Channels: 48
Modulation: FM
Indicator: 8 LED lights for CH1 - CH8; another 6 for Band A - Band F
Transmission power: 13 + / - 1dBm
Antenna type: omnidirectional cloverleaf
Antenna impedance: 50 ohm
Sensor: 1/4 inch CMOS
Input format: NTSC / PAL switchable
Pixels: 720 x 540px ( PAL ); 640 x 480px ( NTSC )
Resolution: 600TVL
Wide-angle lens: 120 degree ( H ); 100 degree ( V )
Power: 200 - 215mA at 5V DC input
Operating voltage: 2.9 - 5.5V
Operating temperature: -10 to +60 Deg.C
Specification
General |
Type: Frame Kit |
|---|---|
Battery |
Battery (mAh): 3.7V 600mAh 25C
Flying Time: 5~6mins |
Camera |
Camera Pixels: 720 x 540px ( PAL ); 640 x 480px ( NTSC )
Video Resolution: 600TVL Video Standards: NTSC,PAL |
Dimension and Weight |
Product weight: 0.055 kg
Package weight: 0.160 kg Product size (L x W x H): 6.35 x 6.35 x 3.20 cm / 2.5 x 2.5 x 1.26 inches Package size (L x W x H): 12.00 x 12.00 x 5.00 cm / 4.72 x 4.72 x 1.97 inches |
Package Contents |
Package Contents: 1 x SPC90 Frame Kit, 1 x Battery, 4 x Propeller |
