SPC Maker 100SP 100mm Brushless FPV Racing Drone F3 BLheli_S 40CH RunCam Micro Swift 600TVL Camera 11.1V BNF
Description:
Brand name: SPC Maker
Product model: SPC 100SP
Wheelbase: 100mm
Size: 80mm*94mm*35mm
Material: 3K carbon fiber
Weight: 77g (without battery)
Flight weight: 110g (include battery)
Thickness of bottom plate: 3mm
Thickness of side plate: 1.5mm
Motor: SPC Maker S1104 7500KV brushless motor
ESC: 15A mini 4 in 1 BLheli_S ESC (2-4S LiPo)
Flight controller: Omnibus F3
Firmware of flight controller betaflight_3.2.0_OMNIBUS F3
Propeller: 50mm 2035 3-blades propeller
Receiver: original Frsky XM+, compatible DSMX / Flysky
Camera: RunCam Micro Swift 1/3" 600TVL FPV camera 2.3mm lens CCD
VTX: 5.8g 25MW-100MW 40CH
Flight time: 4 minutes
Battery: 11.1V 350mAh 30C lipo battery
VX86-1 Ominibus F3 flight controller
Input: 2-4 Cell LiPo
Bec: [email protected]
Firmware: OMNIBUS F3
Size: 27x27 mm
Mount holes: 20x20 mm
Weight: 3.5 g
-STM32 F303 MCU
-MPU6000 6 axis SPI Gyro & Accelerometer
-Dshot support
-Drag and Drop OSD configured via Betaflight Configurator
-SBUS/PPM AND Spketrum dsm-x Ports
-On-board Video Filter (only can supply 5V to VTX and Camera)
VX86-2 15A 4 IN 1 DSHOT ESC 2-4S Lipo
Continuous Current: 15A
Burst Current: 25A≥10S
Input Voltage: 2S-4S LiPO
BEC: No
Dimensions: 29x31mm
Weight: 4.9g
Firmware: BLHeLi_S
Input signal: Dshot150 & Dshot300 & Dshot600(PWM are not recommended)
VX86-3 25mW/100mW 5.8G 40CH 5645-5945MHz VTX
Input voltage: 5-6V
Power: 25mW/100mW can be select
Operation Current: [email protected]@25mW/[email protected]@100mW
Frequency range: 5.8G 40CH 5645-5945MHz
Dimensions: 17x22mm
Weight: 2.5g
Independent external power amplifier for better signals.
RunCam Micro Swift 1/3" 600TVL FPV camera 2.3mm lens CCD
Horizontal Resolution: 600TVL
Lens: 2.3mm Lens(M8) FOV145°
Signal System: NTSC
S/N Ratio: >60dB (AGC OFF)
Electronic Shutter Speed: 1/60~100,000
Auto Gain Control (AGC): Yes
Back Light Compensation (BLC): Yes
Min. Illumination: [email protected]
WDR: D-WDR
DNR: 2DNR
Day/Night: Color/Auto/B&W
Power: DC 5-36V
Net Weight: 5.6g
Dimensions: 19mm*19mm*19mm
Compatible:
1. DSM2 Receiver Support Spectrum/JR(DSM2 protocol) DEVO10/DEVO 7E(with deviation firmware).
2. Frsky Receiver Support FRSKY taranis X9D/X9D PLUS(D16 mode), and XJT (D16 Mode), DJT DFT DHT Transmitter.
3. Flysky Receiver Support FS-I6FS-I6X.FS-I6S.FS-TM8.FS-TM10.FS-I10 and other second-generation AFHDS 2A protocol remote control.
Package include:
1 x SPC Maker 100SP frame kit
1 x Ominibus F3 flytower
1 x receiver
4 x SPC Maker 1104 7500KV brushless motor
1 x Mini 4 in 1 BLheli_s 15A ESC (2-4S LiPo)
4 x 50mm 2035 3-blades propeller CW
4 x 50mm 2035 3-blades propeller CCW
1 x RunCam Micro Swift 1/3 "600TVL FPV camera 2.3mm lens
1 x 5.8G 25mW-100mW 40CH VTX
2 x 11.1V 350mAh 30C lipo battery (comes without charger)
1 x WS2812 LED board
4 x 3 * 100mm nylon band
1 x 12mm * 150mm magic band
2 x 15mm * 50mm back to back with 3M rubber magic belt
1 x XT60 female plug to XT30 male plug converter
1 x carrying case
1 x carrying case
