Slim-X 200 200mm X Tpye 3K Carbon Fiber DIY Frame Kit with 4mm Plate
Specification:
Item Name: 200mm X Type DIY Racing Frame Kit
Model: Slim-X 200
Wheelbase: 200mm
Material: 3K Full Carbon Fiber
Arm Plate Thickness: 4mm
Center Plate Thickness: 3mm
Weight: 88.42g
Features:
-True "X" structure, 200mm 3K full carbon fiber frame kit, robust and light, only 88.42g
- Inspired by Helix, it allows you to install the ESC either on the top or underneath
- 12 x 4mm combined-locking arms not only enhance the arms but reduce the wind drag
- Camera angle can be fixed at 40 to 50 degree, making it possible to resume racing after a crash
- 3mm insulated fiberglass plate keeps FPV data transmission going well
- Top side can protect your FPV camera as well as an additional sports camera
Recommend Parts: (Not included)
Flight controller: F3 ACRO Flight Control
Recommend Parts: (Not included)
Flight controller: F3 ACRO Flight Control
Motor: DYS FIRE 2206 2300KV Or DYS SE2205 2300KV Motor
ESC: DYS XSD 30A V2 ESC Or DYS XS20A 20A ESC
Propeller: DYS 5045 3-Blade Bullnose Propeller
Propeller: DYS 5045 3-Blade Bullnose Propeller
VTX: DYS MI200 5.8G 40CH 25mW/200mW FPV Transmitter
PDB Board: Matek Systems PDB - XT60
FPV Camera: FOXEER HS1177 600TVL CCD Camera
RunCam Swift
RunCam Swift
Antenna: DYS 5dBi Antenna
Battery: Gaoneng GNB 4S 15.2V 1300mAh 100C Lipo Battery
Package Included:
1x Slim-X 200 DIY Frame Kit
1x XT60 Connector
1x Antenna Connector
2x Cables
1x bag of screws
