Specification:
Brand name: SKYSTARS
Item name: TinyFrog 75X 2019 FPV freestyle Racing Drone
Wheelbase: 75mm
F4 8k flight controller: STM32F405 Six-Axis; OSD; Micro SD; 5V 1.5A BEC
Camera: Turbo EOS2 Camera
VTX: Skystars 25-100MW 5V Version
ESC: SKYSTARS 15A Blheli_S ESC 2-4S
Motor: Skystars ST1103 11000KV
Propeller: Gemfan 40mm
Battery: 300MAH 35c 2S (PNP version without battery)
Receiver: Compatible FrSky D16/ Flysky IBus/ DSMX receiver(option)
Package included:
PNP version:
1x TinyFrog 75X 2019 FPV freestyle Racing Drone PNP
BNF version:
1x TinyFrog 75X 2019 FPV freestyle Racing Drone PNP
1x 300MAH 35c 2S battery
1x Compatible FrSky D16/ Flysky IBus/ DSMX receiver
Battery: 300MAH 35c 2S (PNP version without battery)
Receiver: Compatible FrSky D16/ Flysky IBus/ DSMX receiver(option)
| SKYSTARS KOKO F405 FC |
Skystarts KOKO F405 FC
Item name: F405 Betaflight Flight Controller
Input power: 7.4-16V (2-4S)
BEC: 5V/1A
MCU: STM32F405
Gyro: MPU6000
OSD: AT7456
Mounting hole: 25*25mm
Weight: 3.75g
FC Features
- Supports Betaflight and Cleanflight.
- Incould socked head especially for beginners.
- Incould WS2182 RGB led on the board.
|
| SKYSTARS KOKO 15A BL_S ESC |
KOKO Blheli_s 4IN1 ESC
Item name:koko 15A ESC
Input voltage: 2-4S (7.4V~16V)
Continue current: 15A×4
Burst current: 15/18A (4S)
BEC: NO
Mounting: 20.5x20.5mm / φM2
Size:25X24X5MM
Weight: 3.4g
ESC Features:
- 4in1 ESC for brushless tiny whoop supports DSHOT 600, BLHELIs firmware.
- 2 oz. copper PCB allows up to 18A maximum continuous current.
- Supports BLHelis pass-through for easy ESC upgrade and configuration.
- On this version added more CAPS to reduce power noise.
|
| Skystars 25-100MW 5V VTX |
Output power: 25mW/100mW switchable
Control mode:button OR Channel changes and Pitmode setting through PWM
With a microphone, you can switch the audio flexibly
BAT: 5V, BEC 170mA
Video system: NTSC/PAL
Frequency: 5.8GHz 5 bands 40channels
Weight: 1.4 g
Dimension: 14*15*3mm
|
Package included:
PNP version:
1x TinyFrog 75X 2019 FPV freestyle Racing Drone PNP
BNF version:
1x TinyFrog 75X 2019 FPV freestyle Racing Drone PNP
1x 300MAH 35c 2S battery
1x Compatible FrSky D16/ Flysky IBus/ DSMX receiver
