| Specification | |
| Frame Kit |
Wheelbase: 90mm TOP Plate Thickness: 1mm Bottom Plate Thickness: 2mm Side Plate Thickness: 1.5mm Material: 3k Carbon Fiber |
| Flight Controller |
Micro F4 Flight Control Board ( D-Shot Version) MPU: MPU6000-SPI CPU: STM32F405RGT6, dual 8K. Built-in Betaflight OSD to adjust PID BEC Output: 5V@3A Size: 25x25mm board, Installing Hole: 20x20mm, mounting holes (M2) Weight:2.3g Support Subs/PPM/DSMX receiver |
| Brushless ESC |
15A 2-4S Blhelis 4 in 1 ESC: Input Voltage: 2S Lipo battery Constant Current: 15A Peak Current: 20A BEC Ouput: NO Firmware: BLhelis Size: 27x27mm (main board) 27x31mm ( including pad) Installing Hole: 20x20mm, M2 Weight: 4g MOS Tube: TOP QUALITY MOSFET Support Damped Mode, Oneshot125, Oneshot42, Multishot, Dshot150/300/600, forward and reverse |
| VTX |
Mini FPV Transmitter Output power: 25mW/100mW/150mW switchable Control mode:button OR Channel changes BAT: 7-26V,BEC 5V-1A 180mA----150mW Video system: NTSC/PAL Frequency: 5.8GHz 5 bands 40channels, with Raceband: 5645-5945 MHZ Size: 24*24mm(L*W),Hole:20*20mm Weight: 2.4g |
| Brushless Motor | DS1104 KV7500, race edition |
| Camera |
Image Sensor: 1/3" CMOS sensor Horizontal Resolution: 800TVL Lens: 2.3mm Lens FOV: 115 degree(2.3mm) Signal System: PAL / NTSC S/N Ratio: >50dB(AGC OFF) Min.illumination: 0.1Lux/1.2F Day/Night: Auto Power: DC 5V Net weight: 3g Dimensions: 18mm * 14mm * 13mm |
| Propeller | GF1940 3-blade |
| Weight |
PNP Version: Drone weight: 61.3g Package weight: 144g PNP+FS-RX2A Pro Receiver Version: Drone weight:69g Package weight: 154g PNP+ XM Receiver Version: Drone weight:65g Package weight: 150g |
Package Included:
PNP Version
1 x 90MM Frame Kit
1 x F4 Flight Controller
1 x 15A 2-4S Blhelis 4 in 1 ESC
1 x 5.8G 40CH 25mW/100mW/150mW switchable VTX
4 x DS1104 KV7500 motor
1 x 800TVL Camera
8 x GF1940 Propeller
1 x 5v Buzzer
1 x Battery Strap
1 x Brass Antenna
PNP+Receiver Version
1 x 90MM Frame Kit
1 x Flysky FS-RX2A Pro Receiver/ FrSky XM Receiver
1 x F4 Flight Controller
1 x 15A 2-4S Blhelis 4 in 1 ESC
1 x 5.8G 40CH 25mW/100mW/150mW switchable VTX
4 x DS1104 KV7500 motor
1 x 800TVL Camera
8 x GF1940 Propeller
1 x 5v Buzzer
1 x Battery Strap
1 x Brass Antenna
