Specification:
Brand name: SKYSTARS
Item name: EAGLE-221 racing drone PNP/ BNF
Receiver: without receiver/ IBUS(FLYSKY) receiver/ XM+(FRSKY) receiver (option)
| Frame kit |
Wheelbase: 221mm
Arm Plate Thickness: 6mm
TOP&Bottom Plate Thickness: 2mm
Side Plate Thickness: 2mm
Material: 3k Carbon Fiber
Weight: 80g
|
| Flight controller |
Micro F4 Flight Control Board ( D-Shot Version)
MPU: ICM20608
CPU: STM32F405RGT6,dual 8K
Input Voltage: 2-6S Lipo
Built-in Betaflight OSD to adjust PID
BEC Output: 5V@3A
Size: 30.5x30.5mm board, 3mm mounting holes (M3)
Weight:7g
Support Subs/PPM/DSMX receiver
|
| ESC |
40A 2-5S Blheli_32 4 in 1 ESC:
Input Voltage: 2-5S Lipo battery
Constant Current: 40A
Peak Current: 50A
BEC Ouput: [email protected]
CPU: STM32F051 BLHELI_32 firmware
Size: 36x36mm (main board)
Installing Hole: 30.5x30.5mm, M3
Weight: 10g
MOS Tube: TOP QUALITY MOSFET
Support Damped Mode, Oneshot125, Oneshot42, Multishot, Dshot150/300/600/1200, forward and reverse
|
| VTX |
FPV Transmitter
Output power: 25mW/200mW/500mW/800mW switchable
Control mode:button OR Channel changes and Pitmode setting through PWM
With a microphone, you can switch the audio flexibly
BAT: 7-26V,BEC 5V-1A
310mA----800mW
Video system: NTSC/PAL
Antenna: MMCX
Frequency: 5.8GHz 5 bands 40channels
Weight: 4.2 g
Dimension: 36*36*4.85mm
Mounting Hole: 30.5mmx30.5mm
|
| Motor | skystars 2306 KV 2600, race edition |
| Camera |
Model skystarts micro HD ccd camera
Image Sensor: 1/3" SONY Super HAD II CCD
Horizontal Resolution: 600TVL
Lens: 2.3mm Lens
FOV: 130 degree(2.3mm)
Signal System: PAL / NTSC
S/N Ratio: >60dB(AGC OFF)
Electronic Shutter Speed: PAL:1/50 ~ 100,000; NTSC:1/60 ~ 100,000
AutoGain Control(AGC): YES
Back light compensation(BLC): YES
Min.illumination: 0.01Lux/1.2F
WDR: D-WDR
DNR: 2DNR
Day/Night: Color / Auto / B&W
Power: DC 5 to 36V
Net weight: 5.6g
Dimensions: 19mm * 19mm * 19mm
|
| Propellers | GF5052 5inch 2-balde |
| RGB LED | LED with programming tail LED |
| Antenna |
Pagoda2
Weight: 8g
Size: 25mm x 25mm
Gain: 1.6dbic
Axial ratio: 1.0 (near perfect)
Bandwidth: 5.5GHz-6.0GHz
Radiation Efficiency: 95%
VSWR: <=1.22
Connector: MMCX
Works great as both a transmitting or receiving antenna
Compatible with other styles of 5.8GHz RHCP antennas
|
Package included:
1x EAGLE-221 racing drone PNP/ BNF
1x battery strap
1x battery non-slip pad
