Scisky-Mul-A Integrated Scisky 32 A FPV Flight Controller Supports Cleanflight Baseflight 12g

Scisky-Mul-A FPV flight control board is integrated with a Scisky 32 A flight control board (supports both Cleanflight and BaseFlight firmware, onboard buzzer and three color LED tail lights), a MW OSD, a DCDC power and a 5.8G analog video transmitter (max output is 500MW), it also includes several kinds of connection port.

Features:

1)Supports both Cleanflight and Baseflight firmware;

2)Onboard buzzer and three full color LED tail lights;

3)The 5.8G analog video transmitter applied a clock generator of 10PPM accuracy (most clock generators on market are of 30PPM accuracy)

4)The 5.8G analog video transmitter supports FAT SHARK goggles;

5)The video transmitter port is IPX;

6)Independent receiver (supports DSMX/DSM2/SBUS/6CH-PWM) signal processor;

7)Supports GPS ( only when the receiver signal is through the independent receiver signal processor)

8)STM32F103CBT6/72MHz;

9)Onboard sensors: MPU6050, HMC5983(option), MSR5611(option);

10)Supports outside compass and sonar;

11)Onboard receiver (option);

12)Option for digital video transmitter port ( at the same position for onboard receiver, so customer can only choose one between the two);

13)Working voltage: 7.4~18V (equals 2~4S lipoly, for 6S use, customer needs to place an order specially)

14)Size: 79*30*8mm (not including the tail lights)

15)Weight: 12.0g (including the heatsink, not including VTX antenna and onboard receiver)

Without baroceptor or compass.

Package included:

1 x Scisky-Mul-A Integrated Flight Controller
