RunCam Robin + Mini DVR Remote Control 700TVL 1.8/2.1mm FOV 160/145 Degree 4:3 NTSC & PAL Switchable CMOS FPV Camera - 37.00 €

RunCam Robin + Mini DVR Remote Control 700TVL 1.8/2.1mm FOV 160/145 Degree 4:3 NTSC & PAL Switchable CMOS FPV Camera
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


RunCam Robin + Mini DVR Remote Control 700TVL 1.8/2.1mm FOV 160/145 Degree 4:3 NTSC & PAL Switchable CMOS FPV Camera

Description:
Item name: Robin
Color: Orange / Black (Optinal)
Image Sensor: 1/3" 120dB WDR CMOS
Horizontal Resolution: 700TVL
Lens: 1.8mm (M8) FOV160°, 2.1mm(M8) FOV 145° (Optinal)
Mirror/Flip:Available
Signal System:NTSC / PAL Switchable
S/N Ratio:>50dB
Electronic Shutter Speed:Auto
Auto Gain Control (AGC):Auto
Min. Illumination:[email protected]
WDR:120dB
DNR:2DNR
Day/Night: Color/B&W
Menu Control:JOYSTICK
Power:DC 5-36V
Current: 120mA@5V, 50mA@12V (Optional)
Housing Material: ABS
Net Weight:5.5g
Dimensions:L19mm*W19mm*H18mm
Latency:6ms(Min)


Item name: Mini FPV DVR Module

Power in: DC 3.3-5.5V
Work Current: 250mA Max
Power out: DC 5V @ Max 250mA
Video in: CVBS@1Vp-p 75Ω
Video out: CVBS@1Vp-p 75Ω
Encoder: MJPEG@AVI
Resolution: VGA(640 x 480) @ 30fps(NTSC)/25fps(PAL)
Audio in: MIC
Micro SD Card: Max 32G
Dimension: 25 x 25mm @20 × 20 M2 holes
Net Weight: 3.5g

Remote Control Version
Using the Speedy Bee App to set the Remote control function, you can start/stop recording through the remote control. For example, you can bind the recording function to the ARM mode, and the DVR will start recording when the ARM mode is activated. Otherwise, the DVR will stop recording.

Method 1. Automatic association (App iOS >= 1.0.8, Android >= 1.0.7)




Method 2. Manual association
Open the App (iOS >= 1.0.8, Android >= 1.0.7)=> select the Help Center=>click RunCam DVR-S => select Telemerty Control




Features:
* Designed for Mini FPV Racing Drone! ( 25*25mm @ 20*20mm M2 holes)
* Lossless video output for VTX! (Since it has been loaded to the DVR, it needs to synchronize the video amplification output)
* Black technology! Can record high-frequency vibration motor audio without access to MIC!


Runcam Robin FPV Camera Manual, click here

Package Included:

1x Runcam Mini FPV DVR Module
1x Runcam Robin Camera
1x 1928 ABS bracket
1x Set of screws
1x 3pin FPV silicone cable
1x Manual
