Description:
Brand Name: Runcam
Item Name: RunCam Racer FPV Racing Camera With DVR01 Module
Specifications of RunCam Racer:
Image Sensor: Super WDR CMOS Sensor
Horizontal Resolution: 700TVL
Lens: 2.1mm(M8) FOV 150°
Screen Format: 4:3 / Widescreen (Switchable on OSD menu)
Signal System: PAL
Mirror/Flip: Available
Integrated OSD: Yes
One Touch Scene Setting: Personal / Lightrax / Outdoor / Indoor / Cloudy / Twilight
S/N Ratio: >50dB
Electronic Shutter Speed: Auto
Min. Illumination: [email protected]
WDR: Super WDR
Day/Night: Auto
Power: DC 5-36V
Current: 110mA@5V / 40mA@12V
Housing Material: ABS
Net Weight: 5.5g
Dimensions: L19mm*W19mm*H18mm
Power in: DC 3.3-5.5V
Work Current: 250mA Max
Power out: DC 5V @ Max 250mA
Video in: CVBS@1Vp-p 75Ω
Video out: CVBS@1Vp-p 75Ω
Encoder: MJPEG@AVI
Resolution: VGA@640 x 480@30(NTSC) 25(PAL)
Audio in: MIC
Micro SD Card: Max 32G
Dimension: 25 x 25mm @20 × 20 M2 holes
Net Weight: 3.5g
Features:
Features:
Designed for Mini FPV Racing Drone ( 25*25mm @ 20*20mm M2 holes).
Lossless video output for VTX (Since it has been loaded to the DVR, it needs to synchronize the video amplification output).
Black technology, can record high-frequency vibration motor audio without access to MIC.
English Manual for RunCam Racer, Click Here
Package Included:
1 x CameraRunCam Racer
1 x 1928 ABS bracketRunCam Racer
1 x Aluminum bracketRunCam Racer
1 x 6pin FPV silicone cableRunCam Racer
1 x Set of screwsRunCam Racer
1 x Runcam DVR01 Mini FPV DVR Module
1 x Set of M2 screws
1 x SD card protector
1 x 3pin FPV silicone cable (Female)
1 x Runcam DVR01 Mini FPV DVR Module
1 x Set of M2 screws
1 x SD card protector
1 x 3pin FPV silicone cable (Female)
2 x Manual
