Click here to download the manual:Manual.pdfTX200U .PDF
Specifications:Model: RunCam Micro Sparrow
Image Sensor: 1/3" CMOS Sensor
Horizontal Resolution: 700TVL
Lens: 2.1mm (M8) FOV145°/16:9
Signal System: NTSC/PAL Switchable on OSD menu
Integrated OSD: Yes
S/N Ratio >50dB (AGC OFF)
Electronic Shutter Speed PAL: 1/25~100,000; NTSC: 1/30~100,000
Auto Gain Control (AGC) : LOW/MIDDLE/HIGH
Min. Illumination: [email protected]
WDR: LOW/MIDDLE/HIGH
DNR: 2DNR
Day/Night: EXT/COLOR/BW/AUTO GEN
Power: DC 5-36V
Working Current: 12V@70mA / 5V@170mA
Dimensions: 19mm*19mm*17mm
Net Weight: 4.6g
| Model | RunCam TX200U |
| Frequency Channel | 5.8G 48CH |
| Output Power | 25mW / 200mW |
| Working Current | 5V@150~400mA |
| Voltage out | 5V@max 250mA |
| Voltage in | 1S 3.5-5.5V |
| Video Input Impedance | 75 Ohm |
| Antenna | U.FL 5.8G 2dB Omni antenna |
| Weight | 2.5g (with antenna) |
| PCB Size | 19mm*19mm |
1. RunCam Micro Sparrow WDR 700TVL DC 5-36V COMS 16:9 FPV Camera.
2.NTSC/PAL Switchable on OSD menu.
Package included:
1 x RunCam Micro Sparrow
1 x Set of screws
1 x 3pin FPV sillcone cable
1 x 5D-OSD menu cable
1 x Manual
AND
1 X TX200U
1 X Set of screws
