Parameters
| Model | RunCam Micro Sparrow 2 |
| Image Sensor | Super WDR CMOS Sensor |
| Horizontal Resolution | 700TVL |
| Lens | 2.1mm â(M8)â FOV150° |
| Screen Format | 4:3 |
| Signal System | NTSC / PAL |
| Mirror/Flip | Available |
| Integrated OSD | Yes |
| One Touch Scene Setting | Personal / Lightrax / Outdoor / Indoor / Cloudy / Twilight |
| S/N Ratio | >50dB |
| Electronic Shutter Speed | Auto |
| Min. Illumination | [email protected] |
| WDR | Super WDR |
| Day/Night | Auto |
| Power | DC 5-36V |
| Current | 120mA@5V / 50mA@12V |
| Housing Material | ABS |
| Net Weight | 4.5g |
| Dimensions | L19mm*W19mm*H17mm |
| Model | RunCam TX200U |
| Frequency Channel | 5.8G 48CH |
| Output Power | 25mW / 200mW |
| Working Current | 5V@150~400mA |
| Voltage out | 5V@max 250mA |
| Voltage in | 1S 3.5-5.5V |
| Video Input Impedance | 75 Ohm |
| Antenna | U.FL 5.8G 2dB Omni antenna |
| Weight | 2.5g (with antenna) |
| PCB Size | 19mm*19mm |
User Manual : https://www.runcam.com/download/RunCam_TX200U_manual.pdf
Package Included
1x Camera
1x Aluminum bracket
1x Set of screws
1x 6pin FPV silicone cable
1x OSD Key-press Board
1x Manual
AND
1 X TX200U
1 X Set of screws
