WDR level 1-6 available
Mirror & Flip image available
Remote Control Version
1. Flight controller wiring (Take UART3 for example)
2. Betaflight 3.3 or above setting
2. Betaflight 3.3 or above setting
3. Remote control (Take Mode-2 for example)
Description:
Model: RunCam Micro Eagle
Image Sensor: 1/1.8" CMOS Sensor
Horizontal Resolution: 800TVL
FOV: FOV 170 @ 16:9FOV 140 @ 4:3â
Screen Format: 16:9 / 4:3 Switchable on OSD menu
Signal System: NTSC / PAL Switchable on OSD menu
Mirror/Flip: Yes
S/N Ratio: >50dB
Electronic Shutter Speed: Auto
Max Gain: 1-9 Level
Min. Illumination: [email protected]
WDR: Level 1-6 available
Day/Night: Auto/External/Color/B&W
Power: DC 5-36V
Current: 200mA@5V / 90mA@12V
Housing Material: ABS
Net Weight: 8.5g
Dimensions: L19mm*W19mm*H22mm
Features:
Mirror & Flip image available
16:9 / 4:3 Switchable on OSD menu
NTSC / PAL Switchable on OSD menu
Package included:
1x Camera
1x Aluminum bracket
1x Set of screws
1x 3pin FPV silicone cable
1x Manual
