RunCam Eagle 2 Pro + Mini DVR Remote Control Global WDR OSD Audio 800TVL 1/1.8" CMOS FOV 170 Degree 2.1mm 16:9/4:3 Switchable FPV Camera
Click here to download the manual:Manual.pdf
Specifications:
Model: RunCam Eagle 2 Pro
Image Sensor: 1/1.8" CMOS Sensor
Horizontal Resolution: 800TVL
Lens: FOV 170 2.1mm @ 16:9 FOV 140 2.5mm @ 4:3?
Screen Format: 16:9 / 4:3 Switchable on OSD menu
Signal System: NTSC / PAL Switchable on OSD menu
Integrated OSD: Yes
Integrated MIC: Yes
S/N Ratio >50dB
Electronic Shutter Speed: Auto
Max Gain: 1-9
Min. Illumination: [email protected]
WDR: Global WDR
Day/Night: Auto/External/Color/B&W
Power: DC 5-36V
Working Current: 12V@90mA / 5V@200mA
Housing Material: ABS
Dimensions: L28mm*W26mm*H28mm
Net Weight: 15g
Features:
1. Screen Format: 16:9 / 4:3 Switchable on OSD menu.
2. Global WDR, CMOS Sensor.
3. INTEGRATED OSD / MIC.
Item name: Mini FPV DVR Module
Power in: DC 3.3-5.5V
Work Current: 250mA Max
Power out: DC 5V @ Max 250mA
Video in: CVBS@1Vp-p 75Ω
Video out: CVBS@1Vp-p 75Ω
Encoder: MJPEG@AVI
Resolution: VGA(640 x 480) @ 30fps(NTSC)/25fps(PAL)
Audio in: MIC
Micro SD Card: Max 32G
Dimension: 25 x 25mm @20 × 20 M2 holes
Net Weight: 3.5g
Remote Control Version
Using the Speedy Bee App to set the Remote control function, you can start/stop recording through the remote control. For example, you can bind the recording function to the ARM mode, and the DVR will start recording when the ARM mode is activated. Otherwise, the DVR will stop recording.
Method 1. Automatic association (App iOS >= 1.0.8, Android >= 1.0.7)
Method 1. Automatic association (App iOS >= 1.0.8, Android >= 1.0.7)
Method 2. Manual association
Open the App (iOS >= 1.0.8, Android >= 1.0.7)=> select the Help Center=>click RunCam DVR-S => select Telemerty Control
Features:
* Designed for Mini FPV Racing Drone! ( 25*25mm @ 20*20mm M2 holes)
* Lossless video output for VTX! (Since it has been loaded to the DVR, it needs to synchronize the video amplification output)
* Black technology! Can record high-frequency vibration motor audio without access to MIC!
Package included:
1 x Camera
1 x Aluminum bracket
1 x Set of screws
1 x 5pin FPV silicone cable
1 x 3pin FPV silicone cable
1 x 2pin extension cord for menu cable
1 x 5D-OSD menu cable
1 x Manual
1x Runcam Mini FPV DVR Module
