RCD3002 Remote Controlled Glow Plug Driver Auto-Booster With Buzzer

Description:
RCD3002 is a kind of remote controlled driver for glow plug, customers can control the RCD3002’s working status through the switch channel on the transmitter. The device shares the same battery pack with the receiver.

Time limit and low voltage protection, in order to ensure safe flying, the device will stop working when the trigger time is more than 5 minutes or the voltage is lower than 4.5V. Short circuit and over-heat protection work effectively when the system is short circuited and over-heat after long time flying, as soon as it returns to normal, the device resumes working.

It can adjust output current automatically according to the working status of the glow plug, to ensure the glow plug’s working temperature the best, even if the glow plug is drowned into the fuel, it still can keep on a normal working temperature.

The device is high efficiency and interference resistance as it is drove through low frequency impulse width directly, but the resistance of the battery can also influence its working state, in some cases, the glow plug won’t become hot and red because of the high resistance of the battery.

Specification:
Item Name: Remote Controlled Glow Plug Driver
Item NO.: RCD3002
Working Voltage: 4.5V-8.4V
Weight: 13g (with wires and clip)

Application:
All kinds of engines with glow plug
Helicopter and airplanes stable 3D flight supporting

Features:
Comes with a buzzer
Pipe head interface
Powered by receiver directly
Red and blue LED lights indicates the present working status
Power consumption of stability supporting mode is less than 600mA
Monitoring and checking power on and off from the glow plug
Time limit, short circuit and low voltage protection

Usage:
The device works in two ways.

(1)Start Mode, output power is the maximum, the glow plug is driven to hot-red state and the engine is ignited easily.

(2) Stable Mode , that is the output power is half, the glow plug is driven to very near hot-red state, it can increase and stabilize the speed by combining with the engine’s own momentum, it is the most power saving mode.

LED Light Description:
Red LED light is off: No supply power, or no control signal,please check the connection.
Red LED flashes slowly: The supply voltage is too high or too low.
Red LED light flashes quickly: Work in stable mode.
Red LED is solid lit: The device is under Start Mode.
Device ON,blue LED is solid lit: The glow plug work well.

Package Included:
1x RCD3002 Remote Controlled Glow Plug Driver
