Realacc Orange85 F3 FPV Racer BNF Dshot 10A ESC 5.8G 40CH 200mW VTX 600TVL 1/4 Cmos Camera 2-3S
Specification Features Chaser88 Frame
Package: 260x120x165mm
Weigh(without battery): 88.7g
Weight (with battery): 88.2g
Package Weigh: 179g
Compatible with 1935 propeller
Compatible with 1106 motor
Can be used with 2-3S battery (Real Test from factory)
Wheelbase: 85mm
Flight time: 3-5 mins
Batterry: 3S 450mah
With direction indicator LED ESC Model: BLHELI-S 10A
Con. Current: 10A
Peak Current: 15A (10S)
Firmware version: BLHELI_S 16.5
BEC: NO
Li-Po Battery: 2-3S
Programming: Yes
Weight: 13G
Size(PCB): 27 x 27 x 5mm
M3 install Pitch: 20 x 20mm
BB2, 48MHZ Chip
Programming: YES
Betaflight passtrough ready
Dshot600 ready(Default)
Support oneshot42 oneshot125 Multishot Dshot Motor
Height: 18.8mm
Width: 14mm
Weight: about 6.5g
Shaft: φ1.5mm
KV (rpm/V): 6000
Voltage: 3.7-11.1V
Battery: 1-3S lipo batter
Flight Width: 14mm
Weight: about 6.5g
Shaft: φ1.5mm
KV (rpm/V): 6000
Voltage: 3.7-11.1V
Battery: 1-3S lipo batter
Controller F3+BEC
Input: 2-4S LIPO
Output voltage: 5V/3A
STM32F3 CPU
ICM-20608-G Accelerometers and Gyroscopes SPI
MicroUSB socket
Weight: 3.68g
Size(PDB): 27x27mm
M3 hole: 20x20mm Receiver Frsky receiver:
Compatible Frsky 8CH Receiver
Work mode :D8 Mode
Output: PPM/SBUS
Number of channels: 8
Range: Approx 800m
Weight: 3g
Dimensions: 12 x 25mm
Flysky receiver:
Item Name:FS-A8S Receiver
Channels: PPM 8CH, i-BUS 18CH
Model type: Multi-rotor
Model type: Multi-rotor
Frequency range: 2.408-2.475GHz
Band width: 500KHz
Band number: 135
RX Sensitivity: -92 dBm
2.4GHz system: AFHDS 2A
2.4GHz system: AFHDS 2A
Modulation type: GFSK
DSC port: PPM/i-BUS/S.BUS
Transfer method: FHSS
Data output: 1.5mm*3 Pin PPM/i-BUS/S.BUS
Size: 20*14*5.3mm
AIO FPV Transmitter Camera
Output power: 200mWDSC port: PPM/i-BUS/S.BUS
Transfer method: FHSS
Data output: 1.5mm*3 Pin PPM/i-BUS/S.BUS
Input power: 3.3-5V
Current consumption: 3.3-5V, 500mA (type)
Camera resolution: 600TVL
Video system: NTSC
Mini illumination: 1 lux
Field of view: 120 degree viewing angle
Antenna dimensions: 22x29mm diameter
Antenna: 4 lobe right hand circular polarized
Frequency: 5.8GHz 5 bands 40 channel
Size: 20x13x6mm
Weight: 4.57g
Frequency Table Frequency Band A 5865 5845 5825 5805 5785 5765 5745 5725 Frequency Band B 5733 5752 5771 5790 5809 5828 5847 5866 Frequency Band E 5705 5685 5665 5645 5885 5905 5925 5945 Frequency Band F 5740 5760 5780 5800 5820 5840 5860 5880 Frequency Band R 5658 5695 5732 5769 5806 5843 5880 5917
Package Included:
1 X Frame Kit
1 X Receiver
4 X 1106 motor
4 X 1935 Propeller
1 X AIO FPV Camera Transmitter
1 X 4 IN 1 ESC
1 X Flight controller
1 X LED with Buzzer
1 X Battery
1 X Black Alumina Camera protection ring
