Realacc Genius 215 4mm Frame w/ REVO F4 Racerstar BR2205 2600KV Motor RS30x4 Blheli_S ESC 5042 Prop - 115.99 €

Realacc Genius 215 4mm Frame w/ REVO F4 Racerstar BR2205 2600KV Motor RS30x4 Blheli_S ESC 5042 Prop
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


Realacc Genius 215 4mm Frame + REVO F4 + 4X Racerstar BR2205 2600KV Motor + RS30x4 Blheli_S 2-4S ESC + 10 Pairs 5042 3 Blade Propeller






















Items Specifications Features Realacc Genius 215 FPV Racing Frame


Wheelbase: 215mm
Material: 3K carbon fiber
Frame arm: 4mm
Top plate: 2mm
Frame arm top plywood plate: 2mm
Side plate: 1.5mm
Bottom plate: 1.5mm
Weight: 85g(frame + hardware)

Full 3K Carbon Fiber airframe with removable 4mm arms.
2mm top and bottom plates
Compact size for 5" propellers, 215mm motor to motor.
LiPo battery protection plate included.
Designed around popular 26mm sized cams such as the HS1177.
Lightweight and rigid
Racerstar Racing Edition BR2205 2600KV 2-4S Motor

RPM/V: 2600KV
Height: 31.5mm
Width: 27.9mm
Shaft diameter: M5
Motor mount hole size: M3
Weight: 28 grams
Voltage: 2-4S
Battery: 2-4S lipo battery
Internal resistance: Ω
Usage: for 250 260 280 Multirotor Frame Kit
CW screw thread motor comes with red cap
CCW screw thread motor comes with black cap
Long life Japanese NMB ball bearings
Efficient Japanese Kawasaki stator steel
Rare earth magnets stable up to 180
Oxygen free pure commer wires
CNC machined aluminum case
Silicone wire leads
Patented balance techniques
Unique wiring method
Racerstar RS30x4 30A Blheli_S 2-4S 4 in 1 ESC

Con. Current: 30A
Peak Current: 35A (10S)
SBEC: 5V 3A
Support Lipo: 2-4S
Programming: YES
Size (PCB): 36*36mm
Weight: 19g
CC3D REVO F4 STM32F405 Flight Controller

New generation F4 hardware flight controller for FPV race, STM32F405 MCU ,
Frequency up to 168Mhz ,Flight controller firmware is pushing flight controllers to the limit.
Fast loop times enable sophisticated filtering to deliver the locked in, flying on rails feeling.
Betaflight easily delivers 125us (or faster) loop times on the F4 flight controller
Buzzer Port and LED strip Port
MPU6000 SPI Bus
128Mb Flash(16M Byte)
SBUS/PPM input (Pinheaders)
DSM/DSM2/DSMX input(Plug)
6PWM output (Pinheaders)
Only 36x36mm, mount holes 30.5x30.5mm
All through hole pin header Design -no Sh connectors
STM32 F405 MCU, Runs Raceflight CC3D REVO firmware
Works Perfect with Raceflight - preloaded with Raceflight or BetaFlight 3.0
direct Lipo input :1.5A Built-in onboard regulator - NO BEC needed.
Connect direct to a Lipo to power the board and Rx
RaceFlight or Betaflight support on an STM32 F3 with a SPI based MPU6000
gyro - low noise gyro will not force one to soft-mount the fc
10 Pairs Racerstar 5042 3 Blade Propeller
Material: PC
Color: red
Quantity: 10 pairs (the same color)
Mounting hole: 5mm
Weight: 90.2g (10 pairs)
9.02 (1 pair)

Package included:
1 x Realacc Genius 215 FPV Racing Frame
1 x PDB 5V & 12V
1 x CC3D REVO F4 STM32F405 Flight Controller
2 x BR2205 2600KV Brushless Motor CW
2 x BR2205 2600KV Brushless Motor CCW
4 x Racerstar RS30x4 30A Blheli_S
10 x Racerstar 5042 3 Blade Propeller CW
10 x Racerstar 5042 3 Blade Propeller CCW
