Realacc D215 215mm Carbon Fiber 4mm Arm FPV Racing X Frame w/ 5V & 12V PDB
Description:
Brand: Realacc
Item: D215
Wheel base: 215mm
Weight: 110g
Material: carbon fiber
PDB: 5V & 12V
Thickness of frame arm: 4mm
Thickness of side plate: 1.5mm
Thickness of arm plywood: 2mm
Thickness of antenna plate: 1.5mm
Features:
High strength carbon board to ensure that the framework is strong.
4mm thickness frame arms' design.
True "X" frame, suitable for racing and freestyle flying.
With a XT60 PDB integrated BEC (5/12v output)
Recommended Parts (not included):
Flight controller (F4/ F3, mounting hole: 30.5*30.5mm ):
F3 Flight Controller Acro 6 DOF/Deluxe 10 DOF
Omnibus Betaflight F4 Flight Controller
F3 Flight Controller Acro 6 DOF/Deluxe 10 DOF
Omnibus Betaflight F4 Flight Controller
Brushless motor (2204/ 2205/ 2206):
KINGKONG 2204 2300KV Brushless Motor
KINGKONG 2204 2300KV Brushless Motor
Racerstar BR2205 motors
Cobra champion CP2205 motors
Emax RS2205 2300KV motor
DYS SE2205 PRO 2300KV / 2550KV motor
DYS Fire 2206 2100KV 2300KV 2600KV 3-4S Motor DYS SE2205 PRO 2300KV / 2550KV motor
Brushless ESC(20A-30A):
Racerstar RS20A V2 Blheli_S 2-4S ESC 16.5 Dshot600
Racerstar RS20Ax4 V2 20A BB2 48MHz Blheli_S 4 in 1 ESC 16.5 Dshot600
Racerstar RS30A V2 Blheli_S 2-4S ESC 16.5 Dshot600
Racerstar RS30Ax4 V2 BLheli_S BB2 4 in 1 ESC 16.5 Dshot600
DYS XSD 20A 3-4S ESC BLHeli_S Dshot600 Dshot300
DYS XSD 30A 3-5S ESC V2 BLHeli_S Dshot600 Dshot300
DYS XSD 20A 3-4S ESC BLHeli_S Dshot600 Dshot300
DYS XSD 30A 3-5S ESC V2 BLHeli_S Dshot600 Dshot300
Battery (4S 1500mAh):
Infinity 4S 14.8V 1500mAh 70C Graphene LiPo Battery XT60
Infinity 4S 14.8V 1500mAh 70C Graphene LiPo Battery XT60
5 inch 3-blade propeller:
10 Pairs Racerstar 5042 3 BladePropeller 5.0mm Mounting Hole
10 Pairs Racerstar 5051 3 Blade Propeller 5.0mm Mounting Hole
10 Pairs Racerstar 5048 3 Blade Propeller 5.0mm Mounting Hole
10 Pairs Racerstar 5040 3 Blade Propeller 5.0mm Mounting Hole
7 Pairs KingKong 5045 3 blade Rainbow Colorful Propeller
Swift camera
TS5828 VTX
Package included:
1 x Realacc D215 FPV Racing Frame
1 x 5V & 12V PDB
1 x battery strap
8 x M3*6 screw
4 x M3*8 screw
8 x M3*12 screw
4 x M3 nut
1 x M3*29 aluminum post
2 x M3*19 aluminum post
