| Specification | |
| Brand name | Space Gear |
| Item name | GT140mm |
| Frame Kit |
Wheelbase: 140mm Arm Plate Thickness: 3mm Bottom Plate Thickness: 3mm Side Plate Thickness: 1.5mm Material: Carbon Fiber |
| Omnibus F4 Flight Controller |
IMU: MCU6000 |
| Rcharlance 28A 2-4S Blheli_S 4 in 1 ESC |
Input Voltage: 2-4S Lipo battery Constant Current: 28A Peak Current: 30A BEC Ouput: NO Firmware: BLheli_S 16.6 Size: 27x27mm (main board) 31x31mm ( including pad) Installing Hole: 20x20mm, M2 CPU: SILABS EFM8BB21 48MHZ Support Damped Mode, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600, forward and reverse |
|
Rcharlance Micro FPV Transmitter |
Output power: PIT/25mW/100mW/200mW/350mW switchable Control mode:BFOSD control(RX)/button BAT: 7-26V,BEC 5V-1A 240mA----350mW Video system: NTSC/PAL Antenna: IPEX Frequency: 5.8GHz 6 bands 48 channels Size: 24*24mm(L*W),Hole:20*20mm  |
| Rcharlance Micro CAMERA |
Image Sensor: 1/3" SONY Super HAD II CCD Horizontal Resolution: 600TVL Lens: 2.5mm Lens FOV: 130 degree(2.5mm) Signal System: PAL / NTSC S/N Ratio: >60dB(AGC OFF) Electronic Shutter Speed: PAL:1/50 ~ 100,000; NTSC:1/60 ~ 100,000 AutoGain Control(AGC): YES Back light compensation(BLC): YES Min.illumination: 0.01Lux/1.2F WDR: D-WDR DNR: 2DNR Day/Night: Color / Auto / B&W Power: DC 5 to 36V Dimensions: 19mm * 19mm * 19mm |
| 1408-3600KV Motor |
KV: 3600KV |
Package Included:
PNP version
1 x 140mm Carbon Fiber Frame Kit
1 x OMF4 Flight Control Board
1 x 28A Blheli_S 4 In 1 ESC
1 x Micro FPV Transmitter
1 x Micro CAMERA
4 x1408-3600KV
4 x purple propeller CW
4 x purple propeller CCW
1 x Antenna
1 x Battery plate
1 x Battery strap
BNF version
1 x 140mm Carbon Fiber Frame Kit
1 x Receiver
1 x OMF4 Flight Control Board
1 x 28A Blheli_S 4 In 1 ESC
1 x Micro FPV Transmitter
1 x Micro CAMERA
4 x1408-3600KV
4 x purple propeller CW
4 x purple propeller CCW
1 x Antenna
1 x Battery plate
1 x Battery strap
