Rcharlance Space Gear GT140 140mm Carbon Fiber FPV Racing Frame Kit For RC Drone Multi Rotor
Description:
Brand name: Rcharlance
Item name: space gear GT140 frame kit
Material: 3K carbon fiber
Wheelbase: 140mm
Arm plate thickness: 4mm
Bottom plate thickness: 1.6mm
Side plate thickness: 1.5mm
Size: 115 * 90 * 50mm
Weight: 41.3g
Suggested motor: 14-15mm stator diameter motor
Aperture diameter: 20 * 20mm
Features:
Made of 3K carbon fibre material
4mm-thick independent arms, easy to assemble
Tensile X type design, best choice for racing competition
High quality and durable in use
Very light and easy to carry
Recommend parts (package doesn't included):
Brushless motor: 11xx / 12xx / 13xx (mounting holes: 12*12mm)
Brushless ESC: 10A-30A
Flight controller: F3 / F4 (mounting holes: 20*20mm)
Camera: RunCam Micro Swift / Foxxer Arrow Micro (width: 19*19mm)
Propeller: 3 inch
The following products in our website are suitable for this GT140 racing frame:
Brushless motor: Racerstar BR1306 4000KV 1-2S Motor
Brushless ESC: Racerstar Mini RS12Ax4 Blheli_S 2-4S ESC Or Racerstar RS20Ax4 Blheli_S 2-4S ESC
Flight controller: Micro Betaflight Omnibus STM32F4 F4 Or HGLRC Micro F4 AIO Betaflight OSD 5V BEC
Brushless motor: Racerstar BR1306 4000KV 1-2S Motor
Brushless ESC: Racerstar Mini RS12Ax4 Blheli_S 2-4S ESC Or Racerstar RS20Ax4 Blheli_S 2-4S ESC
Flight controller: Micro Betaflight Omnibus STM32F4 F4 Or HGLRC Micro F4 AIO Betaflight OSD 5V BEC
Camera: RunCam Micro Swift 2 Or RunCam Micro Swift Or Foxeer Arrow Micro Pro
Lipo battery: Eachine 1500mAh 3S 11.1V 25C Battery Or AHTECH Infinity 1500mAh 3S 11.1V 85C Battery
3 inch propeller: Gemfan Flash 3052 3-blade Propeller Or DYS X30303 3 blade propellerOrGeprc 3042 3-Blade Propeller
Lipo battery: Eachine 1500mAh 3S 11.1V 25C Battery Or AHTECH Infinity 1500mAh 3S 11.1V 85C Battery
3 inch propeller: Gemfan Flash 3052 3-blade Propeller Or DYS X30303 3 blade propellerOrGeprc 3042 3-Blade Propeller
Package included:
1 x space gear GT140 frame kit
