Specification:
Brand Name: Rcharlance
Model: CF215
Item Name: 215mm F4 OSD 5.8G FPV Racer
Version: PNP / BNF ( Optional )
PNP Version: without receiver and lipo battery
BNF Version: with Frsky XM+ Receiver ( without battery )
Wheelbase: 215mm
Arm Plate Thickness: 4mm
Bottom Plate Thickness: 4mm
Side Plate Thickness: 2mm
Material: Carbon Fiber
Weight: 333.4g
| F4 OSD Flight Controller |
IMU: ICM20689 (SPI), up to 32KHz
CPU: STM32F405RGT6.
Black Box: Flash 16M
Input Voltage: 2-6S Lipo
Supported firmware: BetaFlight (pre-loaded ) , CleanFlight
Built-in Betaflight OSD to adjust PID
BLHeli _32 pass-through: support
Automatic voltage monitoring: Yes
BEC output: 5V @1.5A / 3.3V @ 200mA
Mounting Hole: 30.5x30.5mm
-Support Subs/ PPM/ DSMX Receiver |
| 35A BLheli_32 DShot1200 4 in 1 ESC |
Input Voltage: 2-6S Lipo
Con. Current: 30A
Peak Current: 35A
BEC Ouput: NO
Mounting Hole: 30.5x30.5mm
CPU: SILABS EFM8BB21 48MHZ
Support Damped Mode, Oneshot125, Oneshot42, Multishot
Support Dshot150, Dshot300, Dshot600, Dshot1200, forward and reverse
|
| DT2306 2300KV Motor |
Lipo Battery: 2-4S
Spindle diameter: 23mm
Spindle Length: 6mm
Shaft Diameter: 5mm
Motor Size: Φ33.5 × 39.1mm
Thrust: 2600g (16V 5048 3-blade prop )
|
| 5048 3-Blde Propeller |
Size: 5048 5x4.8 Mounting Hole: 5mm Color: Purple Quantity: 4 CW & 4 CCW |
| Rcharlance VX30 5.8G 48CH FPV Transmitter |
Output Power: 25/200/600/800mW (Switchable) Input Voltage: 7-24V Extra Features: smart audio, 0.01mW (parameter-adjusting mode) Power Supply: 5V camera @ under 0.3A max. Output Voltage: 25mW@100mA ; 200mW@200mA (12V) 600mW-@270mA ; 800mW-@300mA (12V) Range: up to 4km with omnidirectional RHCP antennas Antenna Connector: MMCX, RP-SMA Port connector: JST, 4pin Dimension: 30.5x30.5mm Supports smart audio (remote parameter adjustment) |
| 600TVL CCD FPV Camera |
Sensor: 1/3 Sony SUPER HAD II CCD
Horizontal Resolution: 600TVL
TV System: PAL / NTSC
5D-OSD Button: Yes
Input Voltage: 12V DC
Dimension: 25X25MM (W*L)
Menu (OSD): English menu
White Dot Repair: Support
Image Adjustment: Support
Weight: 14.6g (with bracket)
Power Consumption: 70mA
|
| Frsky XM+ 16CH Reciver (BNF version only) |
Dimension: 21.5x12x3.5mm
Weight: 1.6g
Number of channels: up to 16CH from SBUS
(-15ch for PWM; 16ch RSSI for FC )
Operating Voltage Range: 3.7~10V
Operating Current: 30mA @5V
Operating Range: full range
With RSSI output on board: analog 0~3.3V
Firmware upgradeable
Compatibility: FrSky D16 mode
|
Package Included:
1x 215mm Carbon Fiber Frame Kit
1x F4 Flight Control Board
1x 35A Blheli-32 4 In 1 ESC
1x VX30 FPV Transmitter
1x Micro Camera
4x 2306-2400KV Motor
4x purple propeller CW
4x purple propeller CCW
1x Antenna
1x Battery plate
1x Battery strap
1x Camera bracket(Gopro)
