Racing F4 EVO Flight Controller 2-6S STM32405 CPU Built-in 5V 1A BEC Inverters BMP280 Barometer

Description:
Item name: F4 EVO Flight Controller
Mounting hole: 30.5mm x 30.5mm
Size: 36mm x 36mm
Weight: 5 grams
STM32405 CPU, 168Mhz inc FPU
MicroSD card slot (SD/SDHC, up to 32GB)
ICM20602 accelerometer/gyro (connected via SPI)
BMP280 barometer
Built-in inverters for TELEMETRY and SERIAL RX.
MicroUSB socket for configuration and ESC programming
3 LEDs for 5V, 3V and STATUS (Green, Blue, Red)
BOOT switch for easy firmware upgrades.
Supports Cleanflight, Betaflight and iNav firmware.
Work voltage 2s~6s
Built in 5V 1A BEC

Software features:
3 primary flight modes: Acrobatic, Angle and Horizon
Extensive control and switch configuration
Battery Monitoring and Warnings
Signal Strength Monitoring (RSSI)
Failsafe system
Altitude Hold Mode
Heading Hold Mode
In-flight tuning
Customizable LED colors
Android phone support (via EZ-GUI GCS)

Package included:
1 x F4 EVO flight controller
8 x 3pin though-holes for direct-solder or pin headers for ESC/servo connections
2 x JST SH1.0 cable
16 x 1pin for UARTS
