Racerstar StarF4S 30A Blheli_S Dshot 4 in 1 ESC AIO F4 OSD Flight Controller w/ BEC Current Sensor
Note: The 4 installing holes were linked to the possitive of power. ( battery +)
Therefore, must use the plastic screws or any others non-conductive screws to install.
If not, the FC/ESC/Receivers will be brunt.
Specification: ( Manual)
Brand Name: Racerstar
Model: StarF4S
Model: StarF4S
Item Name: 30A Blheli_S 4 in 1 ESC AIO F4 OSD Flight Controller with BEC and Current Sensor
Lipo Battery: 2-4S
Con. Current: 30A
Peak Current: 35A (10S)
BEC: 5V @1A
Programming: YES
F4 FC + OSD + BEC + Current Sensor
Input Voltage: 2-4S Lipo
Output Voltage: 5V@1A
Sensor: STM32F4 CPU
ICM-MPU6000 Accelerometers and Gyroscopes SPI MicroUSB socket
Size(PCB): 36x36mm
Weight: 22g
Features:
- Built-in F4 Flight Control Board integrated with OSD
- BB2, 48MHZ Chip
- Blheli_S Firmware,
- 4 in 1 ESC, Super small size (36*36mm) and light weight, easy to install and use
- With 5V 1A BEC
- With Current Sensor
-Support 2-4S Lipo Battery
- Support Oneshot42, Oneshot125, Multishot and 16.5 Dshot600
- All codes use damped light mode.Damped light does regenerative braking, causing very fast motor retardation, and inherently also does active freewheeling.
Package Included:
1x Racerstar 30A 4 in 1 ESC Buit-in F4 OSD FC
2x Cable
1x bag of screws
1x Manual
