Description:

Brand Name: QX-Motor

Item Name: Ducted fan with brushless motor set

Ducted Fan: 70mm 12 blades

Motor: QF2827(9) brushless motor

Specifications of Motor:
KV 2600 Idle Current @10.0V 2.0A Configuration 12N8P No.of Cells(Lipo) 4S Stator Diameter 22mm Max Continuons Current(A)/60s 62A Stator Length 27mm Max Continuons Power(W)/60s 1000W Shaft Diameter Φ4mm Max Efficiency >70.5% Motor Dimension 24x48mm Internal Resistance 0.035oh,s Weight 107g Recom. ESC 80A
Tested With 80A ESC:
Prop Volts(V) Amps(A) Watts(W) Thruse(g) Thrust(oz) Efficiency(g/w) 70FAN 16.5 62.0 1023 1800 63.49 1.76 70FAN 16.5 61.0 1006.5 1500 52.91 1.49

Package Included:
1X QX-Motor QF2827(9) 70mm 12 Blades Ducted Fan With 2827-2849 2600KV Brushless Motor
