QX-Motor QAA 2814 600KV 900KV 1250KV 3-6S Brushless Motor CCW For X-UAV Talon RC Airplane Multicopter - 21.99 €

QX-Motor QAA 2814 600KV 900KV 1250KV 3-6S Brushless Motor CCW For X-UAV Talon RC Airplane Multicopter
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


QX-Motor QAA2814 600KV/900KV/1250KV 3-6S Brushless Motor CCW For RC Airplane Multicopter













Description:
Brand Name: QX-Motor
Item Name: QAA2814
KV: 600KV,900KV,1250KV (optional)
Motor Type: CCW
Configuration: 12N14P

Shaft Diameter: 28mm
Stator Length: 14mm
Dimension: 35*36mm
Weight: 92g
Idle Current: [email protected]
No. of Cell: 3-6S
Max. Continuous Power: 600W
Max. Continuous Current: 25A

Test Data:
KV Prop Volt(V) Amps(A) Watts(W) Thrust(g) Thrust(oz) Efficiency(g/w) Efficiency(oz/w) 600KV APC11*47 22.2 4.4 98 750 26.46 7.68 0.27 22.2 8.6 191 1250 44.09 6.55 0.23 22.2 10.0 222 1380 48.68 6.22 0.22 22.2 12.0 266 1560 55.03 5.86 0.21 22.2 16.4 364 1900 67.02 5.22 0.18 22.2 19.5 433 2180 76.90 5.04 0.18 900KV EMP12*6 11 27.3 300 1980 69.84 6.59 0.23 1250KV APC9*6 11 31.0 341 1550 54.67 4.55 0.16 14.8 48.6 719 2400 84.66 3.34 0.12
Features:
Waterproof design,can work in rain and safe operation in 150℃ environment.
Suitable for RC Airplane and multicopters,especially X-UAV Talon.

Package Included:
1x QX-Motor QAA2814 Motor
