QX-Motor 70mm 6 Blades EDF Unit With QF2827 2300KV/3500KV Brushless Motor

Description:
Brand Name: QX-Motor
Item Name: EDF unit with brushless motor set
EDF Unit: 70mm 6 blades
Brushless Motor: QF2827-2300KV,QF2827-3500KV(optional)

Specifications of 2300KV Motor:
KV 2300 Idle Current @10.0V 1.3A Configuration 12N8P No.of Cells(Lipo) 6S Stator Diameter 22mm Max Continuons Current(A)/60s 45A Stator Length 27mm Max Continuous Power(W)/60s 1000W Shaft Diameter Φ4mm Max Efficiency >71% Motor Dimension 28x48mm Internal Resistance 0.028ohMs Weight 107 Recom. ESC 50A
Tested With 50A ESC:
Prop Volts(V) Amps(A) Watts(W) Thrust(g) Thrust(oz) Efficiency(g/w) Efficiency(oz/w) 70FAN 22.2 43.0 954.6 1900 67.02 1.99 0.07
Specifications of 3500KV Motor:
KV 3500 Idle Current @10.0V 1.3A Configuration 12N8P No.of Cells(Lipo) 3-4S Stator Diameter 22mm Max Continuons Current(A)/60s 70A Stator Length 27mm Max Continuous Power(W)/60s 1000W Shaft Diameter Φ4mm Max Efficiency >70.5% Motor Dimension 28x48mm Internal Resistance 0.012ohMs Weight 107 Recom. ESC 85A
Tested With 100A ESC:
Prop Volts(V) Amps(A) Watts(W) Thrust(g) Thrust(oz) Efficiency(g/w) Efficiency(oz/w) 70FAN 11.1 54.0 599.4 1300 45.86 2.17 0.08 70FAN 14.8 74.5 1102.6 1950 68.78 1.77 0.06
Package Included:
1x QX-Motor 70MM 6 Blades EDF Unit With QF2827 Brushless Motor
