PUDA XBL 140 140mm 3 Inch Mini RC Drone FPV Racing Frame Kit 4mm Arm Carbon Fiber
Description:
Brand name: PUDA
Item name: XBL 140mm Frame Kit
Wheel base: 140mm
Material: carbon fiber
Wheel base: 140mm
Material: carbon fiber
Bottom plate thickness: 4mm (middle layer is cut along the weave)
Pod plates thickness: 2.5mm
Frame weight: 41g
Features:
True X frame design
Slim arm design produces less drag and almost eliminated prop wash.
Thick carbon fiber bottom and pod plates.
Designed fo Runcam Swft Micro can be angled up to 90 degrees.
Designed for 1306-1407 motors with 3" props.
Comes with a cemera mount to support most AIO camera.
Optional sleeve (F1) for more customization.
Includes motor guards.
Slidable FC/ESC design to accomodate different sizes.
Camera lens are fully protected.
Components are stackable up to 21mm.
Recommended parts (not included):
Flight controller: F3 (Piko BLX ) / F4 (mounting holes: 20x20mm)
4 in 1 brushless ESC: 10~25A (mounting holes: 20x20mm)
Brushless motors: 1306~ 1407
Camera: Runcam Swift Micro or similar (up to 20mm wide), or AIO camera like the the TX02 /TX03
VTX: 200mw VTX03
Micro RX: LemonRX or Micro Frsky
Lipo battery: 3S 600-800mah or 4S-600-800mah (XT30 Lipo plug)
Propeller: 3 inch
Package included:
1 x PUDA XBL 140mm Frame Kit
