Description:
Item name: FPV VTX Camera
Frequency: 5.8GHz
Channel: 40CH
Bands: A, B, E, F, R
Bands: A, B, E, F, R
Output power: 0/25mW/50mw/200mW Switchable
Input power: 3.2-5.5V
Working current:
95MA-110MA (0mW) shutdown status
250mA-510mA (25mW) 14Dbm
270mA-640mA (50mW) 17dBM
330mA-740mA (200mW) 23dBM
Camera resolution: 600VTL M7 lens
Lens wide angle: 120° FOV 150° DFOV
Mini illumination: 1 lux
Mini illumination: 1 lux
Video system: NTSC
Channel control: one button (the button is channel increment function)
Display: 1 digital display LED
Antenna: Clover antenna/IPEX antenna
Frequency: 5.8GHz 5 bands 40 channels, with Raceband: 5658-5917 MHz.
Size: 19.5*14mm(L*W)
Weight: 5g
Features:
* Super mini size and light weight
* Five bands 40 channels with Raceband, show on LED Digital Display.
Operation Instruction:
1. Powering on the vtx, blue LED display 0, indicating the vtx is powered on, but it is in off status without any transmission.
2. Short-press the button to change channel (CH), digital display will change syschronously. Digital display changes syslically from 1-8.
3. Long-press the button for 2 seconds until digital display flicker. Then short-press the button to change the frequency band (FR), digital display will change synchronously. Digital display changes cyclically from A, B, E, F, R.
4. Long-press the button for 5 seconds until digital display flicker. Then short-press the button to change the power, 25mW/50mW/200mW (one hyphen stands for 25mW, two hyphens stand for 50mW, and three typhens stand for 200mW).
5. 5 seconds after setting, CH, FR and power will flicker alternately.
Notice: The vtx has memory for settings. To change the settings, please repeat steps as above.
Frequency and channel frequency table:
| Band | CH1 | CH2 | CH3 | CH4 | CH5 | CH6 | CH7 | CH8 |
| Band-A | 5865 | 5845 | 5825 | 5805 | 5785 | 5765 | 5745 | 5725 |
| Band-b | 5733 | 5752 | 5771 | 5790 | 5809 | 5828 | 5847 | 5866 |
| Band-E | 5705 | 5685 | 5665 | 5645 | 5885 | 5905 | 5925 | 5945 |
| Band-F | 5740 | 5760 | 5780 | 5800 | 5820 | 5840 | 5860 | 5880 |
| Band-r | 5658 | 5695 | 5732 | 5769 | 5806 | 5843 | 5880 | 5917 |
Package Included:
1 X NTSC Super Mini 5.8G 40CH 0/25mW/50mw/200mW Switchable VTX 600TVL FPV Camera
