Micro 20x20mm VTX-OSD 5.8G 40CH 25mw-200mw FPV Transmitter Integrate OSD 1.2A Fliter BEC for F3
Specification : User Manual
Item Name : VTX-OSD
Channles : 40
Frequency Range: 5645-5945mhz
Frequency Range: 5645-5945mhz
Fully Adjustable Power : 25mW - 200mW (default 25mW)
PID Tuning Capable
Built In Battery Status Monitoring
Integrated Flight Timer System
VTx Channel Configurable via the OSD
Connector type: UFL
Piko fc NOT included
Mounting Hole Distance : 20mm x 20mm
Weight: 5g
Features :
Intergrate LC 5V 1.2A Fliter BEC , input 4.5-36V
Intergrate LC 5V 1.2A Fliter BEC , input 4.5-36V
Raceband Ready Frequency Layout
Adjustable power 25mW-200mW
Integraded MWOSD Function
Can use remote control transmitter and OSD to adjust its FPV power and channel
Can use remote control transmitter to adjust the PID.
Specifically Designed for the F3
Suitable for 110-115 Micro Racer
Frequency:
Frequency Band A 5865 5845 5825 5805 5785 5765 5745 5725
Frequency Band B 5733 5752 5711 5790 5809 5828 5847 5866
Frequency Band A 5865 5845 5825 5805 5785 5765 5745 5725
Frequency Band B 5733 5752 5711 5790 5809 5828 5847 5866
Frequency Band E 5705 5685 5665 5645 5885 5905 5925 5945
Frequency Band F 5740 5760 5780 5800 5820 5840 5860 5880
Frequency Band R 5658 5695 5732 5769 5806 5843 5880 5917
Package Included :
1 x VTX-OSD Integraded 40CH 5.8G 25mW - 200mW VTX OSD 1.2A Fliter BEC
1 x RHCP Antenna
2 x UFL to SMA Female Cable
1 x 5P Board
2 x Screw Set
