Specification:
Brand name: Lumenier
Item name: 2207-11 1750KV JohnnyFPV V2 Bardwell Brushless Motor
| KV | 1750 |
| Configuration | 12N14P |
| Windings | 11 turn DLRK |
| Termination | D (Delta) |
| Stator Diameter | 22mm |
| Inner Shaft Diameter | 4mm |
| Idle Current @12.6v (Io) | 1.1A |
| Cells (LiPo) | 2-6S (5" prop on 6s) |
| Max Continuous Current (A) 60s | 30A |
| Max Burst Current <10s | 40A |
| Max Continuous Power (W) 60s | 480W |
| Max Efficiency Current | (2.2-6A) 80% |
| Internal Resistance (Rm) | 180mΩ |
| Motor Wire Length | 140mm |
| Motor Connection | Bare Wire |
| Motor Dimension | 27x20mm |
| Weight | 30g (short wires) |
Feature:
Minimal base design shedding an additional 2g of weight
Single piece 4mm steel shaft with a screw termination in the base for easy maintenance
Anti-slip grip deck for the propeller machined into the aluminum bell
3 colors and 3 KV's to perfectly match your flying style and setup
Long 140mm motor wires for ultra clean setups with a 4in1 ESC even on 6" builds
Package Included:
1 x Lumenier 2207-11 1750KV JohnnyFPV V2 Motor
1 x Lumenier M5 Black Aluminum Low Profile Lock Nut (CW)
4 x M3x6 Button head screws
