Long Wires New DYS XM30A mini ESC Electronic Speed Controller For High KV Power
Description:
Input voltage: 3-6s Lipo
BEC: NO
Size(mm): 38L*16.5W*6H
Type: BLHeli Bootloader & Firmware
Weight: 9.26g
Built-in capacitor
Specially designed for high KV power racing motors.
Features:
-XM series ESC is the upgraded version of the SN series with advanced processor, a basic frequency up to 50MHz, and faster overall processing capacity to better support high KV motors
-Designed for quick multi-rotor throttle response
Twisted pair cable is used to deliver throttle signal, reducing signal crosstalk while further stabilizing copper wire transmission
-New miniaturization and ultra-low resistance MOSFET, powerful flow resistance, and professional MOS Drive chips improve efficiency
-Newly designed PCB board improves impact resistance.
Sub-miniaturization design reduces weight while still providing a high performance filtering capacitor
-Refresh rate of throttle signal up to 500Hz, compatible with all modern flight controllers, including the Naze32 Rev6 and SP Racing F3
-Ultra-high speed Oneshot125 with 3000Hz refresh rate provides quick, smooth throttle response
-Fully programmable via USB port, with two-way and 3D modes for high speed racing and acrobatics.
Package Included:
1 x ESC
