LDPower FR2306 2306 2450KV 2750KV 3-4S Brushless Motor for RC Drone FPV Racing
Specification:
Brand Name: LDPower
Model: FR2306
Item Name: 2306 2450KV 2750KV 3-4S Brushless Motor
KV: 2450KV / 2750KV (Optional)
N/P: 12N14P
Shaft Diameter: 5mm
No Load Current@10V: 1.9A (2450KV )
No Load Current@10V: 1.9A (2450KV )
2.22A (2750KV)
Max Sustained Current: 42A ( 2450KV )
48A ( 2750KV )
Max. Power: 621.6W ( 2450KV )
710.4W ( 2750KV )
Max. Power: 621.6W ( 2450KV )
710.4W ( 2750KV )
Inner Resistance: 37.2mΩ ( 2450KV )
30.8mΩ ( 2750KV )
Prop Shaft Diameter: M5
Cable Length: 100mm ( 20AWG)
Weight: 32.85g
Testing Table:
2450KV Version
Voltage (V)Prop ( Inch)Throttle Load Current (A)Power (W)RPMThrust (G)Effiency ( G/W)14.85045 3-Blade30%9.77144.596161144553.1550%15.09223.332190526412.8765%19.51288.748213307892.7385%28.73425.2042514210652.50100%34.23506.6042705112102.39
Prop Shaft Diameter: M5
Cable Length: 100mm ( 20AWG)
Weight: 32.85g
Testing Table:
2450KV Version
Voltage (V)Prop ( Inch)Throttle Load Current (A)Power (W)RPMThrust (G)Effiency ( G/W)14.85045 3-Blade30%9.77144.596161144553.1550%15.09223.332190526412.8765%19.51288.748213307892.7385%28.73425.2042514210652.50100%34.23506.6042705112102.39
2750KV Version
Voltage (V)Prop ( Inch)Throttle Load Current (A)Power (W)RPMThrust (G)Effiency ( G/W)14.85045 3-Blade30%12.21180.708171315202.8850%19.1282.68208107352.6065%23.95354.46231558822.4985%35.53525.8442730111622.21100%43.54644.3922919113722.13
Package Included:
1x FR2306 2450KV OR 2750KV Motor
8x Screws
2x M5 Nuts
