Specification:

Input voltage: 6.5-36V (input voltage is lower than 6.5V, current accuracy is not accurate, LCD display below 5.5V is not normal)

Output voltage: 1.2-32V, factory default output 5V.

Output current: It can work stably for 3.5A for a long time, and can reach 4.5A with enhanced heat dissipation (adjustable current limit is about 4.2-4.5A)

Output power: natural heat dissipation 50W (within 3.5A), enhanced heat dissipation 75W

Voltage display: resolution 0.05V, range 1.2-32V, accuracy ± 0.1V (for customers with strict precision requirements)

Current display: resolution 0.005A, range 0-4.5A, accuracy ±0.05A (for customers with strict precision requirements)

Conversion efficiency: about 94%

Working current: about 30mA

Input reverse connection protection: Yes

Output anti-backflow: None (If charging the battery, first power on the module and then connect the battery, and ensure that the battery voltage is lower than the output voltage; after charging, first pull the battery and then power off the module. If there are conditions, please connect the output positively. Current anti-backflow diode

Short circuit protection: Yes

Size: 70.5 * 48.4 * 28mm

Weight: 71g

Packaging included:

1 X Power Supply Module Board
