Specification Brand name LANCH Item name Monster 76mm F4 FPV Racing Drone Frame Kit Wheelbase: 76mm
Material: 3K carbon fiber
Lateral board thickness: 1.5mm
Main board thickness: 2mm Motor 1104 8000KV ( only supports 2S LiPo Propeller 1630 3-blade ( red, yellow, transparent at random ) Receiver PNP: no receiver
BNF FrSky Receiver: 2.4GHz 8CH, 600m receive distance, PPM / SBUS signal output, 5V input voltage, compatible with DHT / DFT / DJT / XJT / X9D Plus / X9E transmitter
BNF FLYSKY Receiver: 2.4GHz 8CH, more than 400m receive distance, PPM / SBUS signal output, 3.3 - 5.0V input voltage, only compatible with AFHDS 2A transmitters Battery 7.4V 500mAh 20C LiPo F4 Flight Controller Processor: STM32F405RGT6
IMU: MPU6000 connected via SPI
Version: 6DOF ( no barometer nor electronic compass )
BEC output: 5V 1A
Integrated OSD: yes
Firmware: betaflight_3.1.0_OMNIBUSF4
Function: supports buzzer, voltage monitoring, LED ESC programming
Power supply: 2 - 4S LiPo
Compatible receiver: SBUS, PPM, DSMX receivers
Mounting hole: M2.5, 20x20mm
Dimension: 27 x 27mm
Weight: 8.5g 4-in-1 10A ESC Input: 2-4S LiPo/2-4S HV LiPo
BEC output: no
Con.Current: 10A
Peak Current(5s):15A
Firmware: Blheli_S
Processor: SILABS EFM8BB21F16G
MOSFET: TPN2R703NL
Support: DSHOT, Oneshot
Size: 27x31mm
Weight: 3.7g AIO VTX Camera Video transmitter: 5.8G 48CH 25mW
Current: 180mA
Input voltage: 5V
Horizontal resolution: 700TVL
TV system: NTSC / PAL ( auto )
Field of view: 120 degree ( horizontal ), 100 degree ( vertical )
Impedance: 50 ohm
Size: 15x12x6.5mm
Weight: 3g LED and buzzer Single LED size: 4.5 x 4.5 x 1.5mm
Buzzer size: 10 x 10 x 5mm
Audible alarm: 80dB
Input voltage: 5V Size and weight Frame Size: 76MM*76MM*50MM (high is without antenna)
Package Size: 120x120x120mm
Weight: 53g ( with battery )
Package Weight: 183g


Package Included:

PNP Version
1 X Monster 76mm FPV Racer
1 X Battery
4 X CW propeller
4 X CCW propeller
1 X Screwdriver
1 X Battery strap
1 X Battery sticker

BNF Version
1 X Monster 76mm FPV Racer
1 X Receiver ( Flysky / Frsky)
1 X Battery
4 X CW propeller
4 X CCW propeller
1 X Screwdriver
1 X Battery strap
1 X Battery sticker
