Kingkong 210 210MM FPV Racer Quadcopter RTF with CMOS Camera 5.8G 200mW VTX Flysky i6 Transmitter
Description:
Brand Name: Kingkong
Item Name: 210 PNP
Thickness of Upper Plate: 1.5±0.2mm
Thickness of Bottom Plate: 3±0.2mm
Flight Controller: Micro CC3D, Micro NZ32
Propeller: 5040
Motor: 2204(2-4s)
ESC: BLHELI 12A 2-4s
VTX: 200mW 5.8G
Antenna: RHCP, SMA
Remote Control System: Flysky FS-i6
Battery: 3S 1300mAh 25C Battery
Frame Weight: 322g
12A ESC:
Item name: KINGKONG 12A ESC
Continuous current: 12A
Instantaneous current: 20A (5 seconds)
Input voltage: 2-4S(7-17V)
BEC Linear: No
Programming: Yes
Weight: 7.4g
Size: 31*16*49mm
2204 Motor:
Item name:2204 2300KV Brushless Motor
KV:2300
Max Thrust:440G
No.of cell :2-3S
Framework:12N14P
Propeller:5"-6"
Length:32.2MM
Weight:25G
Shaft:5MM
Diameter:27.9MM
800TVL CMOS Camera
Format: PAL,NTSC
View Angle:115°
Lens Type: F2.0/2.8MM
Voltage: DC5V-17V
Weight: 16.7g
5.8G 200mW 40CH VTX
Video Format: NTSC/PAL
Voltage: 7-24V
Transmitting Power: 200mW
FS-i6 Specifications:
Channels: 6 Channels
Model Type: Glider/Heli/Airplane
RF Range: 2.40-2.48GHz
Bandwidth: 500KHz
Band: 142
RF Power: Less Than 20dBm
2.4ghz System: AFHDS 2A and AFHDS
Code Type: GFSK
Sensitivity: 1024
Low Voltage Warning: less than 4.2V
DSC Port: PS2;Output:PPM
Charger Port: No
ANT length: 26mm*2(dual antenna)
Weight:392g
Power: 6V 1.5AA*4
Display mode: Transflective STN positive type, 128*64 dot matrix VA73*39mm,white backlight.
Size: 174x89x190mm
On-line update:yes
Color: Black
Certificate: CE0678,FCC
Model Memories: 20
Channel Order: Aileron-CH1, Elevator-CH2, Throttle-CH3, Rudder-CH4,Ch 5 & 6 open to assignment to other functions.
FS-iA6 Specifications:
Channels: 6 Channels
Model Type: Fixed-wing/Glider/Airplane
RF Range: 2.40-2.48GHz
Bandwidth: 500KHz
Band: 142
RF power:less than 20dBm
RF.receiver sensitivity:-105dBm
2.4ghz System: AFHDS 2A
Code Type: GFSK
ANT length: 26mm
Weight:6.4g
Power:4.0-6.5V
Size: 40.4x21.1x7.35mm
Color: Black
Certificate: CE,FCC
i-BUS port: NO
Data Acquisition port:NO
Features:
3mm carbon frame body,strong,light-weight frame
12A 2S-4S Opto BLHeli Speed controllers
Powerful KINGKONG 2300kv motors
Pre-tuned micro CC3D flight control system
Standard camera holders, the vertical angle is adjustable
High brightness multicolor rear LED with lampshade
Package Included:
1 x 210MM Frame Kit
4 x 2300KV Motor
4 x 12A ESC
20 x 5040 Propeller
1 x 200mW 5.8G VTX
1 x 800TVL CMOS Camera
1 x SMA RHCP 5.8G Antenna
1 x 3S 1300mAh Battery
1 x Battery Charger
1 x Flysky i6 Transmitter
1 x Flysky iA6 Receiver
