JX Servo PDI-6213MG 13KG 120 Degree Metal Gear Digital Coreless Standard Servo
Feature:
- High performance digital standard servo
- High-precision Taiwan-made aluminium gears with hard anodizing
- CNC aluminium middle Shell
- Dual ball bearings
Specification:
Maximum angle: 120°
Maximum Pulse Width: 900-2100us
Dead band: 2μs
Working frequence: 1520μs / 330hz
Motor: high quality core motor
Operating Speed (4.8V): 0.20sec/60°
Operating Speed (6V): 0.18 sec/60°
Stall Torque (4.8V): 11.75kg.cm (163.21oz/in)
Stall Torque (6V): 13.06 kg-cm (181.40 oz/in)
Dimensions: 40.5X20.2X38mm/1.59X0.80X1.49in
Weight: 62g (2.18oz)
Connector Wire Length: JR 265 mm (10.43in)
Bearing: 2BB
Package Included:
1x JX PDI-6213MG Servo
